12
Lowes.com/harborbreeze
1.
1
If you do NOT wish to use the light kit, remove 3
switch housing cap screws (N) from switch housing
cap (M) located on switch housing preassembled to
motor housing (D). Pull down gently on switch
housing cap (M).
Locate wires in switch housing labeled FOR LIGHT
and gently pull molex connections apart in order to
disconnect switch housing cap (M) from switch
housing.
INSTALLING FAN WITHOUT LIGHT KIT
FINAL INSTALLATION
Attach pull chain extensions (CC) or custom pull
chain extensions (not included) to fan and light pull
chains.
Assembly is now complete.
8
8.
Pull Chain Extension x 2
Hardware Used
CC
CC
Molex
Connections
M
N
Switch Housing
D
To Next Page
