SIDE RAIL ASSEMBLY & PARTS LIST CONTINUED
PORTLAND GATE ASSEMBLY & PARTS
1
2
3
6
7
8
5
4
5
9
10
# Part Description Part #
Qty Per
Gate
Notes
1 Portland Gate LH (left hand) 83630 1
741 or 752
2 Portland Gate RH (right hand) 83631 1
3
Trigger Assembly-Top of Portland Gate
84219 1
Top or bottom trigger-
Need 2 per side
4
Trigger Assembly-
Bottom of Portland Gate
84220 1
5 Screw C/P 6-1/2” 63792 2
For Portland Trigger-
Need 2 per side
Lockwasher (not shown) 63457 2
6 Portland Spring 63229 2
Components available
in hardware bag 72112-
parts for one Portland Gate
7 Hinge Pin 17214-S 1
8 Plastic Bushing 11520 1
9 Plastic Grommet 17065 1
Placed on bottom of side rail
for hinge pin
10 “NO STEP” Sticker 62180 1
Put on the bottom of the side rail
inside each Portland Gate.
