HARD 741-CPGP - Under Crib Shelf and Bumpers

SHELF & BUMPERS
7
8
5
66
9
10
9
10
2
3
4
1
11
# Part Description Part # Qty Notes
1
Under Crib Shelf with O2 cut outs-
30” crib 88164 1
Shelf with hardware- no bumpers
included
Under Crib Shelf with O2 cut outs-
36” crib 88165 1
2 Screw 1/4-20x5/8 63392 4
Used to attach Shelf to Bumper3 Jam Nylon Locknut 1/4-20 63413 4
4 Washer 1/4 63443 4
5
Bumper Assembly- 30” crib 84126 2
Assembly includes #6, 7 & 8 only
with bumper plate
Bumper Assembly- 36” crib 84127 2
6 Grey Corner Bumpers 63896 4
7 Screw 8-32x7/8 60129 8
For Grey Corner Bumper
8 K-Nut 8-32 60139 8
9 Button Socket Cap Screw 1/4-20x7/8 60242 6
Used to attach Bumper to the crib
10 Connector Nut 1/4-20 60245 6
11 “NO STEP” Sticker 62180 2
Position: middle of both of the long
shelf sides
