*1904 IV POLE PARTS LIST
The *1904 IV Pole is a standard feature on all of HARD Manufacturing cribs that do not
have a safety top.
# Part Description Qty. Part # Notes
*1904 IV Pole 1 *1904 Complete IV Pole Assembly
1 Screw 1 63392
2 Lock Washer 1 63458
3 Spacer 1 11628
4 Hook 2 11627
Specify color when ordering
5 Washer 2 11555
6 Plastic Spacer 1 62083
7 Release Pin 1 11852
8 Compression Spring 1 63006
9 Plastic Washer 1 11531
Used as release knob
10 Retaining Ring 1 63034
11 Plastic Bracket 2 11553
Available also as a set in hardware bag
72079
12 Plastic Connector 2 11552
13 Screw 4 62047
14 Connector Nut 4 60319
15 Inside Tube ass’y 1 81550 Inside tube- no hardware included
Plug 1 63452 Not shown
Stop Ring 1 81080 Not shown-internal component
Hardware Bag 1 72081
Includes everything listed above
excluding #15
