EZ-Guide® Plus
Overview o
the Menu
Menu Menu option Description Default value
Lightbar Back to Main Menu Return to main menu. —
Display Config Turn on or turn off screen items, such as Progress lines – ON
progress lines, field boundary, or adjacent Adjacent swaths – ON
swath lines and configure the view setting. Field boundary – ON
AB Line – ON
View – Auto
Path display – ON
Contrast/Brightness Adjust the screen contrast and backlight Screen contrast – 10
brightness. Adjust the LED brightness. Screen backlight – Auto
LED brightness – 20
Antenna Offset Distance from the anttena to the implement. 0’0 “
Lightbar Mount Upright. Upright
Inverted – Inverts display and offline LEDs.
Status Text Configure the status text items for the map Map and 3D View
views and the status screen. – Offline Distance
– Swath Number
Status Screen
– Field Area
– Coverage Area
– Speed
– Heading
Data Port Settings Configure the input and output for the Integrated GPS lightbar
data port. – Input – None
– 8N1 4800
– Output rate – 1 Hz
No GPS lightbar
– Input – External GPS
– 8N1 38400
–
Pulse Output Configure the pulse output rate. OFF
Units US – Feet, miles per hour, acres. US
Metric – Meters, kilometers per hour, hectares.
Language Configure operating language for the system. English
ests Run self-, button, LED, LCD, backlight, or GPS –
status tests.
24
