Hardi HC5500 Service Manual

Page 19 of 87
Extended Menu 3 Sprayer type
E3.1
Field sprayer
E3.1.1 Liquid system
[Equalization, Not equalization, Circulation]
Default is Equalization.
Equalization = System with liquid return to tank from
section valves; e.g. EVC.
Not equalization = System without returns to tank;
e.g. EFC on CM05.
Circulation = System where liquid constantly
circulates in the boom lines.
E3.1.2 Dual Line
E3.1.2.1 System type
[Not present, 2 stage, 3 stage]
Default is Not present.
2-stage: Line A will always be open, and Line B can
be switched on and off automatically.
3-stage: Line A switches to B, then Line A comes on
so both A & B are on.
E3
Sprayer
type
E3.1.2.2 Sensor type
[Pressure, Speed]
If a pressure transducer is fitted, pressure is used to
trigger the line change.
E3.1.2.3 System lag
[Second]
Default is 1.0 sec.
System lag prevents oscillation when spray lines
change.
E3.1.2.4 Line overlap
[Second]
Default is 1.5 sec.
System overlap allows the activated spray line to
stabilise before the other line is turned off.
E3.2
Mistblower
E3.2.1 Liquid system
[Equalization, Not equalization, Circulation]
Default is Equalization.
Equalization = System with liquid return to tank from
section valves; e.g. EVC.
Not equalization = System without returns to tank;
e.g. Solenoid controls.
Circulation = System where liquid constantly
circulates in the boom lines
E3.2.2 Sub unit
[Standard, UCR]
Default = Standard (UCR affects menu 3.3)
UCR = Unit Canopy Row. Bases application on the
size of the tree canopy.
