Hardi HC5500 Service Manual

Page 21 of 87
Extended Menu 5 Optional sensors
E5.1
Pressure
E5.1.1
Minimum
Connected
to section
valve PCB.
[-9.9 to 9.9]
Default is 0.0 Bar
4 -20 mAmp sensor.
See sensor for minimum value.
See “Pressure sensor” section.
E5.1.2
Maximum
[0 to 99.9]
Default is 10.0 Bar
See sensor specifications for maximum value.
E5.2
Fan speed
E5.2.1
PPU
Connected
to section
valve PCB.
[0 to 99.99 PPU]
Default is 1
Digital input.
One pulse per revolution = 1.00 PPU.
See “Fan speed” on TWIN section
E5
Optional
sensor
E5.3
TankGauge
E5.3.1
Sensor Type
For sprayers
with
Breakout
PCB or
JobCom.
[Not present, Fillmeter, ME Tank Control,
Hardi]
For Hardi TankGauge, choose Hardi.
E5.3.2
PPU
[0.000 to 999.999 PPU ]
Connect to Breakout PCB or JobCom.
See “TankGauge” section.
Hardi has the TankGauge 0-250mbar pressure
transducer fitted to sump.
E5.X
Sensor x Unit Default
Only with
Breakout
PCB or
JobCom E5.4
Wind speed PPU 1
E5.5
Wind
direction
E5.5.1
min 0
E5.5.2
max 359
E5.6
Air
temperature
E5.6.1
min -20
E5.6.2
max 70
E5.7
Relative
humid
E5.7.1
min 0
E5.7.2
max 100
E5.8
RPM sensor PPU 1
E5.9
Extra 1 PPU 1
E5.10
Extra 2 PPU 1
E5.11
Extra 3
E5.11.1
min 0
E5.11.2
max 5
E5.12
Extra 4
E5.12.1
min 0
E5.12.2
max 5
