GB 05 02 MA
Sprayer setup
RR
RR
R
oadwoadw
oadwoadw
oadw
oror
oror
or
thinessthiness
thinessthiness
thiness
When driving on public roads and other areas where the
highway code applies, or areas where there are special
rules and regulations for marking and lights on imple-
ments, you should observe these and equip implements
accordingly.
RR
RR
R
ear lights (optional equipment)ear lights (optional equipment)
ear lights (optional equipment)ear lights (optional equipment)
ear lights (optional equipment)
The sprayer can be equipped with rear lights (A).
Connect plug for rear lights to the tractor’s 7-pin socket
and check the functions of rear lights, stop lights and
direction indicators on both sides of the sprayer before
driving.
The wiring is in accordance with ISO 1724. (See section
on Technical Specifications).
T250-0002
A A
