Hardi NAVIGATOR 4000 Original Instruction Book

8 - Technical specifications
104
Pump model 463/12.0
Filters and nozzles
Filter gauze width
Temperature and pressure ranges
Spray liquid:
Hydraulics:
Hydraulics operating pressure:
Brakes
Max. wear rates on brake components:
Hydraulic brakes
Max. hydraulic pressure: 150 bar (2176 p.s.i.)
Air brakes
Max. air pressure: 6.5 bar
Power consumption
30 mesh: 0.58 mm
50 mesh: 0.30 mm
80 mesh: 0.18 mm
100 mesh: 0.15 mm
Operating temperature range: 2° to 40° C (36°F to 104°F)
Operating pressure for safety valve: 15 bar (220 psi)
Max. pressure on the pressure manifold: 20 bar (290 psi)
Max. pressure on the suction manifold: 7 bar (100 psi)
Max. operating temperature: 75º C (167ºF)
Tractor: 210 bar (3046 psi)
min. 160 bar (2321 psi)
Sprayer litres Max. drum diameter Min. lining thickness
3000 402 mm (15.8388 in) 4.0 mm (0.15748 in)
4000 402 mm (15.8388 in) 4.0 mm (0.15748 in)
Sprayer Hp kW
3000 100 75
4000 115 86
