Hardi NAVIGATOR 4000 Original Instruction Book

53
5 - Operation
Boom
Safety info
The boom must not be folded/unfolded while driving! Never use the folding/unfolding functions before the sprayer has
been stopped! Failure to do so will damage the boom.
€
DANGER! Before unfolding the boom it is important to connect the sprayer to the tractor to prevent overbalancing
of the sprayer.
€
DANGER! When folding or unfolding the boom, make sure that no persons or objects are within the operating area
of the boom.
€
DANGER! Always follow the guidelines listed below when driving in areas with overhead power lines:
Never use the folding/unfolding functions in areas with overhead power
lines.
Unintended boom movements may cause contact with overhead
power lines.
μ
ATTENTION! A label (ref. no. 978448) follows the sprayer. This label
must be placed in the cabin visible from the operator’s seat.
μ
ATTENTION! Only unfold and fold the boom on level ground.
Manoeuvring of the boom - VHY
The VHY boom is solely controlled by the tractor’s hydraulic levers.
Following operations are carried out by the tractor’s hydraulic control lever(s):
• Raising/lowering of the boom.
• Folding/unfolding of the boom.
• Slanting control (optional equipment).
μ
ATTENTION! Only unfold and fold the boom on level ground.
