3.Installation Diagram
3.1 Install the latch
1.Adjust the length of the latch
according to the distance from the door
hole center to the door edge.(60mm or
70mm)
2.Insert the latch in the hole and tighten
screws.
3.Install the bottom case and strike plate
on door frame.(Accessories numbered 8
and 9 on the page 5 Overview)
