Harman Kardon AVR 139/230 User Manual

Ref. # Part Number
Description
V
alue
CQXAVR142/230 INSTRUCTION MANUAL ASS'Y
CABR03P3PB BATTERY , AAA 3PCS IN PACK
CARTAVR142/230 REMOCON TRANSMITTER ASS'Y
CPB1061W BAG , POLY(ENGLISH/FRANCH) FRANCE LANGUAGE ADDED
CPL0905 STAPLE
CQE1A220Z SHEET , FRONT COVER AVR130/230BK
CQE1A411Z SHEET , BATTERY HARMAN
CQX1A1441Z MANUAL , INSTRUCTION
CSA1A018Z FM 1 POLE ANT
CSA1A020Z ANT , AM LOOP
C4FC240CL TAPE , P.P(24mm*50mm)
C4FC500CL TAPE , OPP
FRONT PANEL ASSY
Ref. # Part Number
Description
V
alue
CBC1A158ZB41 KNOB , MOMS AVR138/230
CBT1A1026MMZB41 KNOB , POWER AVR138/230
CBT1A1028YB41 KNOB , FUNCTION AVR138/230
CGB1A158Y BADGE , FRONT HARMAN/KARDON
CGL1A258Z INDICATOR , POWER
CGW4A427RHWH63 PANEL , FRONT
CHR301 CLAMPER
CMC1A366 PLATE , SHIELD
CMC2A302 PLATE , SHIELD
CMD2A443 BRACKET , SIDE
CMH1A299 HOLDER , AUX
CMH2A215 HOLDER , LED AVR350
CMK2A010 BRACKET , PCB
CMZ1A088Z FILTER , FIP AVR154
CMZ1A120 SHEET , REFLECTION
CTB3+16GFZR SCREW
CTB3+8JFZR SCREW
CN72 CWC4C4A31B250B10 CABLE , CARD (31P,1.25MM,250MM,B,10MM)
FRONT PCB ASSY
Ref. # Part Number
Description
V
alue
COP12185B AVR139/230 FRONT PCB ASS'Y
C278 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C406 CCEA1HKS4R7T CAP , ELECT 4.7UF 50V SMALL SIZE
C513 CCEA1HKS4R7T CAP , ELECT 4.7UF 50V SMALL SIZE
C714 CCBS1H680JT CAP , CERAMIC(68PF/50V) CH UP025SL680J-A-B Z
C716 CCEA1AH331T CAP , ELECT 330UF 10V
C719 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z
C720 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z
C721 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C722 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C723 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C724 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C725 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C726 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C727 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C728 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C729 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J
C735 CCEA1CKS100T CAP , ELECT 10UF 16V
C742 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C793 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C794 CCBS1C222MXT CAP , CERAMIC(2200PF/16V) CH EP025 B222M-A-B J
C795 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z
C796 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z
C805 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C806 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C807 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C808 CCBS1H181KBT CAP , CERAMIC(180PF/50V) CH UP025 B181K-A-B Z
C809 CCEA1AH471T CAP , ELECT 470UF 10V
C812 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C817 CCBS1H100JCT CAP , CERAMIC(10PF/50V) CH UP025CH100J-A-B Z
C843 CCEA1HH100T CAP , ELECT 10UF 50V
C850 HCQI1H102JZT CAP , MYLAR 1000PF 50V J
C851 HCQI1H102JZT CAP , MYLAR 1000PF 50V J
C855 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C856 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C857 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C862 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z
C863 CCBS1H221KBT CAP , CERAMIC(220PF/50V) CH UP025 B221K-A-B Z
C864 CCBS1H221KBT CAP , CERAMIC(220PF/50V) CH UP025 B221K-A-B Z
C866 CCEA1HKS100T CAP , ELECT 10UF 50V SMALL SIZE
C867 CCEA1HKS100T CAP , ELECT 10UF 50V SMALL SIZE
C868 CCEA1CKS470T CAP , ELECT 47UF 16V
C869 CCEA1CKS470T CAP , ELECT 47UF 16V
C870 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z
C871 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z
C872 CCEA1CH331T CAP , ELECT 330UF 16V
C873 CCEA1CH331T CAP , ELECT 330UF 16V
C882 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C889 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
harman/kardon
AVR 139-141-142/230 Service Manual
Page 11 of 83
