FRONT PCB ASSY
Ref. # Part Number
Description
V
alue
C891 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C892 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C893 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J
C894 CCEA1CKS100T CAP , ELECT 10UF 16V
C896 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C897 CCEA1AH471T CAP , ELECT 470UF 10V
C903 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
C905 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
D774 CVD1SS133MT DIODE 1SS133
D775 CVD1SS133MT DIODE 1SS133
D786 CVD1SS133MT DIODE 1SS133
D787 CVD1SS133MT DIODE 1SS133
L702 HLQ02C100KT COIL , AXAIL
Q701 HVTKRC107MT T.R KRC107M
Q722 HVTKRA107MT T.R KRA107M
Q724 HVTKRC107MT T.R KRC107M
Q725 HVTKRC107MT T.R KRC107M
Q734 HVTKTC2874BT T.R , MUTE KTC2874B
Q735 HVTKTC2874BT T.R , MUTE KTC2874B
Q736 HVTKTC2874BT T.R , MUTE KTC2874B
Q737 HVTKTC2874BT T.R , MUTE KTC2874B
Q738 HVTKRC107MT T.R KRC107M
Q739 HVTKTA1271YT T.R KTA1271Y
R582 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R583 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R584 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R585 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R702 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R724 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R725 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R737 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R753 CRD20TF1001T RES , CARBON 1K /1/5W /F
R754 CRD20TF1501T RES , CARBON 1.5K /1/5W /F
R755 CRD20TF1801T RES , CARBON 1.8K /1/5W /F
R756 CRD20TF2701T RES , CARBON 2.7K /1/5W/F
R757 CRD20TF3301T RES , CARBON 3.3K /1/5W/F
R758 CRD20TF5601T RES , CARBON(5.6K/F)
R759 CRD20TF1001T RES , CARBON 1K /1/5W /F
R760 CRD20TF1501T RES , CARBON 1.5K /1/5W /F
R761 CRD20TF1801T RES , CARBON 1.8K /1/5W /F
R762 CRD20TF2701T RES , CARBON 2.7K /1/5W/F
R763 CRD20TF3301T RES , CARBON 3.3K /1/5W/F
R764 CRD20TF5601T RES , CARBON(5.6K/F)
R765 CRD20TF7501T RES , CARBON (7.5K/F)
R781 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R783 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R784 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R786 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R787 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R791 CRD20TJ123T RES , CARBON 12K OHM 1/5W J
R805 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R806 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R824 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R825 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R828 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R829 CRD20TJ681T RES , CARBON 680 OHM 1/5W J
R864 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R865 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R866 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R869 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R871 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R872 CRD20TJ223T RES , CARBON 22K OHM 1/5W J
R873 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R874 CRD20TJ221T RES , CARBON 220 OHM 1/5W J
R875 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R878 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R892 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R893 CRD20TJ333T RES , CARBON 33K OHM 1/5W J
R895 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R896 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R897 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R898 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R899 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R900 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R901 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R902 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R903 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
harman/kardon
AVR 139-141-142/230 Service Manual
Page 12 of 83
