Harman Kardon AVR 1510 Service Manual

AVR 151, 5.1CH RECEIVER, bill of materials
Level Ref# Component Description Drawing No REQ-Qty
.......7 C1428 CCUC1A226KC CAP, CHIP(2012, 10V/22uF) 1
.......7 C1429 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1501 CCUS1H272KC CAP, CHIP(1608, 50V/2700pF) 1
.......7 C1502 CCUS1H272KC CAP, CHIP(1608, 50V/2700pF) 1
.......7 C1503 CCUS1H391JA CAP, CHIP(1608, 50V/390pF) 1
.......7 C1504 CCUS1H391JA CAP, CHIP(1608, 50V/390pF) 1
.......7 C1507 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1510
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1511 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1512
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1515 CCUS1H683KC CAP, CHIP(1608, 50V/0.068uF) 1
.......7 C1516 CCUS1H272KC CAP, CHIP(1608, 50V/2700pF) 1
.......7 C1517 CCUS1H822KC CAP, CHIP(1608, 50V/8200pF) 1
.......7 C1518 CCUS1H391JA CAP, CHIP(1608, 50V/390pF) 1
.......7 C1521 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1524 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1525
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1526
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1529 CCUS1H272KC CAP, CHIP(1608, 50V/2700pF) 1
.......7 C1530 CCUS1H272KC CAP, CHIP(1608, 50V/2700pF) 1
.......7 C1531 CCUS1H391JA CAP, CHIP(1608, 50V/390pF) 1
.......7 C1532 CCUS1H391JA CAP, CHIP(1608, 50V/390pF) 1
.......7 C1535 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1538
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1539 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1540
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1543
CCEC1CMVG471T
CAP,ALUMINUM ELECTROLYTIC (16V/470uF) 1
.......7 C1544
CCEC1CMVG471T
CAP,ALUMINUM ELECTROLYTIC (16V/470uF) 1
.......7 C1545 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1546 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1547 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 C1548 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7
C1552
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1553
CCEC1CMVG100T
CAP,ALUMINUM ELECTROLYTIC (16V/10uF) 1
.......7 C1555
CCEC0JMVG220T
CAP,ALUMINUM ELECTROLYTIC (6.3V/22uF) 1
.......7 C1556 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF) 1
.......7 D1105 CVD1SS355T DIODE , CHIP , SWITCHING 1SS355(T/B) 1
.......7 D1106 CVD1SS355T DIODE , CHIP , SWITCHING 1SS355(T/B) 1
.......7 D1404 CVD1SS355T DIODE , CHIP , SWITCHING 1SS355(T/B) 1
.......7 D1503
CVD1SR159-200H
DIODE, SCHOTTKY 1
.......7 D1504
CVD1SR159-200H
DIODE, SCHOTTKY 1
.......7 D1505 CVD1SS355T DIODE , CHIP , SWITCHING 1SS355(T/B) 1
.......7 D1506 CVD1SS355T DIODE , CHIP , SWITCHING 1SS355(T/B) 1
.......7 IC1001
CVIADV7623BSTZ_A
I.C , HDMI Transceiver (LQFP-144P) 1
.......7 IC1002
CVIMX25L8006EM2I-12G
I.C , SERIAL FLASH(8M) 1
.......7 IC1003
CVITC74VCX541FT
I,C , OCTAL BUS BUFFER (TOSHIBA) TC74VCX541FT(EL,M) 1
.......7 IC1101
CVIISL54220IUZ-T
I.C , USB2.0 Multiplexer(TQFN-10P) ISL54220IUZ-T 1
.......7 IC1103
CVIKSZ8851SNLTR
I.C , ETHERNET PHY (10/100M,QFN-32P)) KSZ8851SNL TR 1
.......7 IC1105 CVIFS1230A I.C , CHORUS3(NETWORK PROCESSOR) FS1230A 1
.......7 IC1106
CVIA3V28S40FTP-G6
I.C , SDRAM(128MBIT,TSOP-54P) 1
.......7 IC1201
CVIAZ1117CH-5.0TRG1
LDO, low dropout three-terminal regulator AZ1117CH-5.0TRG1 1
.......7 IC1202
CVIDB1230HETR
I.C , DC DC CONVERTER(3A,700KHZ,SOP-8P) DB1230HETR 1
.......7 IC1203
CVIDB1514AHETR
I.C,REGULATOR(1.5A,ADJ,CONT,8-SOP-EP) 1
.......7 IC1204
CVIDB1230HETR
I.C , DC DC CONVERTER(3A,700KHZ,SOP-8P) DB1230HETR 1
.......7 IC1205
CVIEML3418-00SE08GRR
I.C , DCDC CONVERTER(SOP-8FD) 1
.......7 IC1206
CVIAZ1117CH-1.2TRG1
LDO , low dropout three-terminal regulator AZ1117CH-1.2TRG1 1
.......7 IC1301
HVICS42528-CQ
I.C , CODEC + DIR (CIRRUS LOGIC) CS42528-CQZ 1
.......7 IC1302
CVICS497024CVZ
EOL item I.C , DSP (CIRRUS LOGIC) CS497024-CVZ 1
.......7 IC1303
HVITC74VHC157FT
I.C, QUAD 2-CHANNEL MUX(TSSOP-16) TC74VHC157FT(EL,M) 1
.......7 IC1304
CVITC74VCX541FT
I,C , OCTAL BUS BUFFER (TOSHIBA) TC74VCX541FT(EL,M) 1
.......7 IC1305
CVIMX25L8006EM2I-12G
I.C , SERIAL FLASH(8M) 1
.......7 IC1308
CVIM12L16161A5TG2Q
I.C, 16MB SDRAM(TSOP-50P) M12L16161A5TG2Q 1
.......7 IC1309
CVINJM2845DL118
I.C, REGULATOR(1.8V/TO-252) NJM2845DL-18-TEL(PB-F) 1
.......7 IC1401
CVISTM32F205ZGT6
I.C , FLASH MCU (32 BIT, 1MB, LQFP 144) 1
.......7 IC1403
CVIDB1510BT3TR33
I.C, REGULATOR(1.0A,3.3V,TO252-(1)) DB1510BT3TR33 1
.......7 IC1405
CRTLM94022BIMG
SENSOR , TEMPERATURE LM94022BIMG 1
.......7 IC1501
CVINJM4580CG
I.C , DUAL OPAMP(SOP-8P) 1
.......7 IC1502
CVINJM4580CG
I.C , DUAL OPAMP(SOP-8P) 1
.......7 IC1503
CVINJM4580CG
I.C , DUAL OPAMP(SOP-8P) 1
.......7 IC1504
CVILM7808RTRL
IC, REGULATOR(1A, 8V) LM7808RTRL 1
.......7 IC1505
CVILM7908RTRL
IC, REGULATOR(1A, -8V) LM7908RTRL 1
.......7 JK1001 CJJ9H008Y JACK, HDMI(TYPE-A, SMT-19P) 1
.......7 JK1002 CJJ9H008Y JACK, HDMI(TYPE-A, SMT-19P) 1
.......7 JK1003 CJJ9H008Y JACK, HDMI(TYPE-A, SMT-19P) 1
.......7 JK1004 CJJ9H008Y JACK, HDMI(TYPE-A, SMT-19P) 1
.......7 JK1005 CJJ9H008Y JACK, HDMI(TYPE-A, SMT-19P) 1
.......7 JK1101 CJJ9L026Z JACK , RJ-45 With TR (SMT) 1
.......7 L1009 CLZ9R005V FERRITE CHIP BEAD(1608/60R, CB03YTYH600) 1
.......7 L1101 CLZ9R018V FERRITE CHIP BEAD(2012/220R, CB05YTYH221) 1
.......7 L1102 CLZ9R018V FERRITE CHIP BEAD(2012/220R, CB05YTYH221) 1
.......7 L1103 CLZ9Z127Z COIL, CHOKE CHIP(2012/180R) DLW21SN181SQ2L 1
.......7 L1104 CLZ9Z128Z COIL, CHOKE CHIP(2012/90R) DLW21SN900SQ2L 1
.......7 L1105 CLZ9Z128Z COIL, CHOKE CHIP(2012/90R) DLW21SN900SQ2L 1
.......7 L1107 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1109 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1110 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1111 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1112 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1113 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1114 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
.......7 L1201
CLQ12E100MRZ
COIL , SMD POWER (10uH/3A) CMI-SPC9H45F-SERIES 1
Harman Kardon
AVR 151 Service Manual
Page 25 of 131

Harman Kardon AVR 1510 Specifications

Audio Specifications

stereo power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
multichannel power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	75dB
frequency response (@ 1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±25 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @ 1kHz
selectivity (±400kHz)	70dB

AM Tuner Specifications

frequency range	520kHz – 1, 510kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	375µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI	Supports up to 4K x 2K

General Specifications

power requirement	120V AC / 60Hz
power consumption	<0.5W (standby); 410W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10 lb (4.6kg)
