AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.......7 L1202 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1203 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1206 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1208 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1209 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1210 CLZ9R005V FERRITE CHIP BEAD(1608/60R, CB03YTYH600) 1

.......7 L1211 CLZ9R005V FERRITE CHIP BEAD(1608/60R, CB03YTYH600) 1

.......7 L1212 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1213 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1215 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1216

CLQ18E1R5NRZ

COIL,SMD POWER(1.5uH/2A) SWPA3015S1R5MT 1

.......7 L1219

CLQ20E3R3NRZ

COIL,SMD POWER(3.3uH/3.2A) 1

.......7 L1220

CLQ20E3R3NRZ

COIL,SMD POWER(3.3uH/3.2A) 1

.......7 L1301 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1302 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1303 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1

.......7 L1401 CLZ9R005V FERRITE CHIP BEAD(1608/60R, CB03YTYH600) 1

.......7 Q1003 CVTRT1P141C T.R,RT1P141C(10K-10K) RT1P141C-T112-1 1

.......7 Q1004 CVTRT1N241C T.R,RT1N241C(22K-22K) RT1N241C-T112-1 1

.......7 Q1005 CVTRT1P141C T.R,RT1P141C(10K-10K) RT1P141C-T112-1 1

.......7 Q1007 CVTRT1P141C T.R,RT1P141C(10K-10K) RT1P141C-T112-1 1

.......7 Q1010 CVTRT1N241C T.R,RT1N241C(22K-22K) RT1N241C-T112-1 1

.......7 Q1409 CVTRT1N141C T.R,RT1N141C(10K-10K) RT1N141C 1

.......7 Q1512

CVTMMBT5551

High Voltage NPN Transistors(SOT-23) 1

.......7 Q1513

CVTMMBT5551

High Voltage NPN Transistors(SOT-23) 1

.......7 Q1514

CVTMMBT5551

High Voltage NPN Transistors(SOT-23) 1

.......7 RN1001 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 RN1002 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 RN1003 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 RN1004 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 RN1005 CRJ104DJ220T RES, CHIP(1608/5%/22ohm*4) 22X4/2012 1

.......7 RN1006 CRJ104DJ220T RES, CHIP(1608/5%/22ohm*4) 22X4/2012 1

.......7

RN1101 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1301 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1302 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1303 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1304 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1305 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1306 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1307 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1308 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1309 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1310 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1311 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1312 CRJ064IJ330T RES, CHIP(1005/5%/33ohm*4) 0402*4 5% 33 OHM 1

.......7 RN1401 CRJ104DJ101T RES, CHIP(1608/5%/100ohm*4) 1

.......7 RN1402 CRJ104DJ101T RES, CHIP(1608/5%/100ohm*4) 1

.......7 RN1403 CRJ104DJ101T RES, CHIP(1608/5%/100ohm*4) 1

.......7 RN1404 CRJ104DJ101T RES, CHIP(1608/5%/100ohm*4) 1

.......7 RN1405 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 RN1406 CRJ104DJ330T RES, CHIP(1608/5%/33ohm*4) 1

.......7 R1001 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1002 CRJ06IJ102T RES, CHIP(1005/5%/1Kohm) RM04JC1K 1

.......7 R1003 CRJ06IJ223T RES, CHIP(1005/5%/22Kohm) RM04JC22K 1

.......7 R1005 CRJ06IJ101T RES, CHIP(1005/5%/100ohm) RM04JC100R 1

.......7 R1006 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1007 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1008 CRJ06IJ102T RES, CHIP(1005/5%/1Kohm) RM04JC1K 1

.......7 R1009 CRJ06IJ223T RES, CHIP(1005/5%/22Kohm) RM04JC22K 1

.......7 R1010 CRJ06IJ102T RES, CHIP(1005/5%/1Kohm) RM04JC1K 1

.......7 R1011 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1012 CRJ06IJ101T RES, CHIP(1005/5%/100ohm) RM04JC100R 1

.......7 R1013 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1014 CRJ06IJ102T RES, CHIP(1005/5%/1Kohm) RM04JC1K 1

.......7 R1015 CRJ06IJ223T RES, CHIP(1005/5%/22Kohm) RM04JC22K 1

.......7 R1016 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1018 CRJ06IJ101T RES, CHIP(1005/5%/100ohm) RM04JC100R 1

.......7 R1019 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1020 CRJ06IJ102T RES, CHIP(1005/5%/1Kohm) RM04JC1K 1

.......7 R1021 CRJ06IJ223T RES, CHIP(1005/5%/22Kohm) RM04JC22K 1

.......7 R1022 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1024 CRJ06IJ101T RES, CHIP(1005/5%/100ohm) RM04JC100R 1

.......7 R1027 CRJ06IJ103T RES, CHIP(1005/5%/10Kohm) RM04JC10K 1

.......7 R1032 CRJ10DJ182T RES, CHIP(1608/5%/1.8Kohm) 00200-0200 1

.......7 R1033 CRJ10DJ182T RES, CHIP(1608/5%/1.8Kohm) 00200-0200 1

.......7 R1034 CRJ06IJ473T RES, CHIP(1005/5%/47Kohm) RM04JC47K 1

.......7 R1035 CRJ06IJ103T RES, CHIP(1005/5%/10Kohm) RM04JC10K 1

.......7 R1037 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1038 CRJ06IJ0R0T RES, CHIP(1005/5%/0ohm) RM04JC0R 1

.......7 R1039 CRJ06IJ0R0T RES, CHIP(1005/5%/0ohm) RM04JC0R 1

.......7 R1040 CRJ06IJ0R0T RES, CHIP(1005/5%/0ohm) RM04JC0R 1

.......7 R1048 CRJ06IJ0R0T RES, CHIP(1005/5%/0ohm) RM04JC0R 1

.......7 R1049 CRJ10DJ394T RES, CHIP(1608/5%/390Kohm) 1

.......7 R1050 CRJ10DF1001T RES, CHIP(1608/1%/1Kohm) RM06FB1K 1

.......7 R1051 CRJ10DF1001T RES, CHIP(1608/1%/1Kohm) RM06FB1K 1

.......7 R1052 CRJ10DF1601T RES, CHIP(1608/1%/1.6Kohm) 1

.......7 R1053 CRJ10DF2001T RES, CHIP(1608/1%/2Kohm) 1

.......7 R1061 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1062 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1063 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1064 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

Harman Kardon

AVR 151 Service Manual

Page 26 of 131
