AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.......7 R1065 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1066 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1101 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1102 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1105 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1106 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1107 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1108 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1110 CRJ10DJ510T RES, CHIP(1608/5%/51ohm) 1608 SIZE 1

.......7 R1111 CRJ10DJ510T RES, CHIP(1608/5%/51ohm) 1608 SIZE 1

.......7 R1112 CRJ10DJ510T RES, CHIP(1608/5%/51ohm) 1608 SIZE 1

.......7 R1113 CRJ10DJ510T RES, CHIP(1608/5%/51ohm) 1608 SIZE 1

.......7 R1115 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1116 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1117 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1118 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1119 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1120 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1121 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1122 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1123 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1125 CRJ10DJ272T RES, CHIP(1608/5%/2.7Kohm) 1

.......7 R1126 CRJ06IJ105T RES, CHIP(1005/5%/1Mohm) RM04JC1M 1

.......7 R1127 CRJ06IJ103T RES, CHIP(1005/5%/10Kohm) RM04JC10K 1

.......7 R1128 CRJ06IJ103T RES, CHIP(1005/5%/10Kohm) RM04JC10K 1

.......7 R1129 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1131 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1132 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1139 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1143 CRJ06IJ101T RES, CHIP(1005/5%/100ohm) RM04JC100R 1

.......7 R1144 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1145 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7

R1146 CRJ10DJ271T RES, CHIP(1608/5%/270ohm) 1608 SIZE 1

.......7 R1148 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1150 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1152 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1153 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1155 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1201 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1202 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1206 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1208 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1211 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1215 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1216 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1220 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1222 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1223 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1224 CRJ10DF1502T RES, CHIP(1608/1%/15Kohm) 1

.......7 R1225 CRJ10DF4702T RES, CHIP(1608/1%/47Kohm) 1

.......7 R1226 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1227 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1228 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

.......7 R1229 CRJ10DF1002T RES, CHIP(1608/1%/10Kohm) 10K /1/10W/F 1

.......7 R1230 CRJ10DF2702T RES, CHIP(1608/1%/27Kohm) 1

.......7 R1231 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1232 CRJ10DF3301T RES, CHIP(1608/1%/3.3Kohm) 1

.......7 R1233 CRJ10DF1802T RES, CHIP(1608/1%/18Kohm) 1/10W 1608 F 18K OHM 1

.......7 R1234 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1237 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1238 CRJ10DF1002T RES, CHIP(1608/1%/10Kohm) 10K /1/10W/F 1

.......7 R1239 CRJ10DF4702T RES, CHIP(1608/1%/47Kohm) 1

.......7 R1250 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1251 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1270 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1271 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1272 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1304 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1307 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1312 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1316 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1319 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1324 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1325 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1326 CRJ10DJ100T RES, CHIP(1608/5%/10ohm) 1608 SIZE 1

.......7 R1327 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1333 CRJ10DJ820T RES, CHIP(1608/5%/82ohm) 1608 SIZE 1

.......7 R1338 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1343 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1344 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1345 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1346 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1349 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1352 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1353 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1354 CRJ10DJ820T RES, CHIP(1608/5%/82ohm) 1608 SIZE 1

.......7 R1355 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1356 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1359 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1360 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1361 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

Harman Kardon

AVR 151 Service Manual

Page 27 of 131
