AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.......7 R1362 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1363 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1364 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1365 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1366 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1368 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1369 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1370 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1371 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1372 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1373 CRJ06IJ330T RES, CHIP(1005/5%/33ohm) RM04JC33R 1

.......7 R1374 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1375 CRJ06IJ820T RES, CHIP(1005/5%/82ohm) RM04JC82R 1

.......7 R1376 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1410 CRJ10DJ105T RES, CHIP(1608/5%/1Mohm) 00200-0095 1

.......7 R1415 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1416 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1417 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1418 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1419 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1420 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1422 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1423 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1424 CRJ10DJ100T RES, CHIP(1608/5%/10ohm) 1608 SIZE 1

.......7 R1425 CRJ10DJ100T RES, CHIP(1608/5%/10ohm) 1608 SIZE 1

.......7 R1434 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1435 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1436 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1437 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1438 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1442 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1445 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7

R1446 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1447 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1448 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1452 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

.......7 R1453 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1454 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1455 CRJ10DJ330T RES, CHIP(1608/5%/33ohm) 00200-0118 1

.......7 R1461 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1464 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1465 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1466 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1467 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1471 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1475 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1477 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1480 CRJ10DJ473T RES, CHIP(1608/5%/47Kohm) 00200-0185 1

.......7 R1481 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

.......7 R1502 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1503 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1507 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1508 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1509 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1510 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1520 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1521 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1525 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

.......7 R1526 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1527 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1528 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1538 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1539 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1543 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1544 CRJ10DJ682T RES, CHIP(1608/5%/6.8Kohm) 1608 SIZE 1

.......7 R1545 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm) 00200-0105 1

.......7 R1546 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 R1563 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1564 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

.......7 R1568 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm) 00200-0119 1

.......7 WF1102 CJP15GA193ZY WAFER, FFC, SMD(15P-1mm, STRAIGHT) 1

.......7 WF1401

CJP23GA299ZN

WAFER, FFC, SMD(23P-1.25mm, STRAIGHT) 1

.......7 WF1402

CJP11GA299ZN

WAFER, FFC, SMD(11P-1.25mm, STRAIGHT) 1

.......7 WF1501

CJP17GA299ZN

WAFER, FFC, SMD(17P-1.25mm, STRAIGHT) 1

.......7 WF1502

CJP27GA299ZN

WAFER, FFC, SMD(27P-1.25mm, STRAIGHT) 1

.......7 X1001

COX28636I120ST

X-TAL, SMD 3.2X2.5, 28.636MHz, 12PF 7V28600001 1

.......7 X1101

COX24576I120ST

X-TAL, SMD 3.2X2.5, 24.576MHz, 12PF 7V24500006 1

.......7 X1102

COX12000I100ST

X-TAL, SMD 3.2X2.5, 12.000MHz, 10PF 7V12000005 1

.......7 X1103

COX25000I120ST

X-TAL, SMD 3.2X2.5, 25.000MHz, 12PF 7V25000009 1

.......7 X1301

COX24576I120ST

X-TAL, SMD 3.2X2.5, 24.576MHz, 12PF 7V24500006 1

.......7 X1401

COX25000I120ST

X-TAL, SMD 3.2X2.5, 25.000MHz, 12PF 7V25000009 1

...3 COP12506I AVR151/230 MAIN PCB ASS'Y 1

......6 C1700 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1701 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1702 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1703 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1704 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1705 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1706 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1707 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

......6 C1708 CCUS1H220JA CAP, CHIP(1608, 50V/22pF) 1

Harman Kardon

AVR 151 Service Manual

Page 28 of 131
