AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

......6 R1827 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R1828 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R1829 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R1836 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

......6 R1837 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

......6 R1839 CRJ10DJ393T RES, CHIP(1608/5%/39Kohm) 1

......6 R1840 CRJ10DJ393T RES, CHIP(1608/5%/39Kohm) 1

......6 R1845 CRJ10DJ271T RES, CHIP(1608/5%/270ohm) 1608 SIZE 1

......6 R1848 CRJ10DJ271T RES, CHIP(1608/5%/270ohm) 1608 SIZE 1

......6 R305 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R306 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R307 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R308 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R311 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R312 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R313 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R314 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R319 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

......6 R321 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

......6 R322 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

......6 R323 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm) 00200-0087 1

......6 R324 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R325 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

......6 R326 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R327 CRJ10DJ101T RES, CHIP(1608/5%/100ohm) 00200-0100 1

......6 R328 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

......6 R329 CRJ10DJ104T RES, CHIP(1608/5%/100Kohm) 00200-0097 1

......6 R686 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R687 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R688 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R689 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R706 CRJ10DJ0R0T RES, CHIP(1608/5%/0ohm) 00200-0090 1

......6

R731 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R732 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R733 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R734 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R735 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R736 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R737 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R738 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R801 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R901 CRJ10DJ753T RES, CHIP(1608/5%/75Kohm) 1608 SYZE 1

......6 R902 CRJ10DJ333T RES, CHIP(1608/5%/33Kohm) 1608 SIZE 1

......6 R917 CRJ14CJ473T RES, CHIP(3216/5%/47Kohm) 1

......6 R918 CRJ14CJ473T RES, CHIP(3216/5%/47Kohm) 1

......6 R919 CRJ14CJ473T RES, CHIP(3216/5%/47Kohm) 1

......6 R920 CRJ14CJ473T RES, CHIP(3216/5%/47Kohm) 1

......6 R925 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm) 00200-0096 1

......6 R928 CRJ10DJ333T RES, CHIP(1608/5%/33Kohm) 1608 SIZE 1

.....5 C1740

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C1741

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C1744

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1745

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1747

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1749

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1752

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1753

CCEA1HH101TC

CAP, ELECT(50V/100uF) 1

.....5 C1767

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C1768

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C1776

CCEA1HH220TC

CAP, ELECT(50V/22uF) 1

.....5 C321

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C501 CCEA2AH100T CAP, ELECT(100V/10uF) 1

.....5 C502 CCEA2AH100T CAP, ELECT(100V/10uF) 1

.....5 C503 CCEA2AH100T CAP, ELECT(100V/10uF) 1

.....5 C504 CCEA2AH100T CAP, ELECT(100V/10uF) 1

.....5 C506 CCKT1H331KB CAP, CERAMIC(50V/330pF/K) CKB 1H 331K 04 FK5 1

.....5 C507 CCKT1H331KB CAP, CERAMIC(50V/330pF/K) CKB 1H 331K 04 FK5 1

.....5 C508 CCKT1H331KB CAP, CERAMIC(50V/330pF/K) CKB 1H 331K 04 FK5 1

.....5 C509 CCKT1H331KB CAP, CERAMIC(50V/330pF/K) CKB 1H 331K 04 FK5 1

.....5 C561 CCEA1HH221T CAP, ELECT(50V/220uF) 1

.....5 C562 CCEA1HH221T CAP, ELECT(50V/220uF) 1

.....5 C563 CCEA1HH221T CAP, ELECT(50V/220uF) 1

.....5 C564 CCEA1HH221T CAP, ELECT(50V/220uF) 1

.....5 C566

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C567

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C568

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C569

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C571

CCBS1H271KBT

CAP , CERAMIC(270PF/50V) CH UP025 B271K-A-B Z 1

.....5 C572

CCBS1H271KBT

CAP , CERAMIC(270PF/50V) CH UP025 B271K-A-B Z 1

.....5 C573

CCBS1H271KBT

CAP , CERAMIC(270PF/50V) CH UP025 B271K-A-B Z 1

.....5 C574

CCBS1H271KBT

CAP , CERAMIC(270PF/50V) CH UP025 B271K-A-B Z 1

.....5 C601 CCCT1H120JC CAP, CERAMIC(50V/12pF/J) CCC 1H 120J 04 FK5 1

.....5 C602 CCCT1H120JC CAP, CERAMIC(50V/12pF/J) CCC 1H 120J 04 FK5 1

.....5 C603 CCCT1H120JC CAP, CERAMIC(50V/12pF/J) CCC 1H 120J 04 FK5 1

.....5 C604 CCCT1H120JC CAP, CERAMIC(50V/12pF/J) CCC 1H 120J 04 FK5 1

.....5 C606 CCCT1H330JC CAP, CERAMIC(50V/33pF/J) CCC 1H 330J 05 FK5 1

.....5 C607 CCCT1H330JC CAP, CERAMIC(50V/33pF/J) CCC 1H 330J 05 FK5 1

.....5 C608 CCCT1H330JC CAP, CERAMIC(50V/33pF/J) CCC 1H 330J 05 FK5 1

.....5 C609 CCCT1H330JC CAP, CERAMIC(50V/33pF/J) CCC 1H 330J 05 FK5 1

.....5 C631

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C632

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

Harman Kardon

AVR 151 Service Manual

Page 30 of 131
