AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.....5 C633

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C634

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C636

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C637

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C638

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C639

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C681

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C682

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C683

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C684

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C716

CCEA1CH220TC

CAP, ELECT(16V/22uF) 1

.....5 C801

CCEA1HH100TC

CAP, ELECT(50V/10uF) 1

.....5 C803 CCCT1H330JC CAP, CERAMIC(50V/33pF/J) CCC 1H 330J 05 FK5 1

.....5 C805 CCCT1H120JC CAP, CERAMIC(50V/12pF/J) CCC 1H 120J 04 FK5 1

.....5 C807

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C808

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C811 CCEA1HH221T CAP, ELECT(50V/220uF) 1

.....5 C813

CCEA1CH101TC

CAP, ELECT(16V/100uF) 1

.....5 C815 CCKT1H331KB CAP, CERAMIC(50V/330pF/K) CKB 1H 331K 04 FK5 1

.....5 C817 CCEA2AH100T CAP, ELECT(100V/10uF) 1

.....5 C819

CCBS1H271KBT

CAP , CERAMIC(270PF/50V) CH UP025 B271K-A-B Z 1

.....5 C852 CCEA1HH220T CAP, ELECT(50V/22uF) 00107-1033 1

.....5 C854 CCEA1HH220T CAP, ELECT(50V/22uF) 00107-1033 1

.....5 C855 CCEA1HH220T CAP, ELECT(50V/22uF) 00107-1033 1

.....5 C856 CCEA1HH220T CAP, ELECT(50V/22uF) 00107-1033 1

.....5 C857 CCEA1HH220T CAP, ELECT(50V/22uF) 00107-1033 1

.....5 C900 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C901 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C910 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C917

CCEA1HH470TC

CAP , ELECT (50V/47uF) 1

.....5 C918 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C919 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5

C931 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C932 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C940

CCEA1AH471TC

CAP, ELECT(10V/470uF) 1

.....5 C971 HCQI1H562JZT CAP, MYLAR(50V/5600pF/J) HPE562J2AP050T 1

.....5 C972 HCQI1H562JZT CAP, MYLAR(50V/5600pF/J) HPE562J2AP050T 1

.....5 C973 HCQI1H562JZT CAP, MYLAR(50V/5600pF/J) HPE562J2AP050T 1

.....5 C980 HCQI1H562JZT CAP, MYLAR(50V/5600pF/J) HPE562J2AP050T 1

.....5 C981 HCQI1H562JZT CAP, MYLAR(50V/5600pF/J) HPE562J2AP050T 1

.....5 C990 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C992 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C993 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C995 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 C997 HCQI1H473JZT CAP, MYLAR(50V/0.047uF/J) HPE473J2AP050T 1

.....5 D581

CVD1SS133MT

DIODE , SWITCHING ISS133(T/B) 1

.....5 D582

CVD1SS133MT

DIODE , SWITCHING ISS133(T/B) 1

.....5 D583

CVD1SS133MT

DIODE , SWITCHING ISS133(T/B) 1

.....5 D584

CVD1SS133MT

DIODE , SWITCHING ISS133(T/B) 1

.....5 D801

CVD1SS133MT

DIODE , SWITCHING ISS133(T/B) 1

.....5 D954

CVD1N4003SRT

DIODE , RECT 1N4003 SRT 1

.....5 D955

CVD1N4003SRT

DIODE , RECT 1N4003 SRT 1

.....5 G901 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 G902 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 Q501

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q502

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q503

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q504

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q511

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q512

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q513

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q514

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q516

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q517

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q518

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q519

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q556

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q557

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q558

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q559

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q561

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q562

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q563

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q564

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q601

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q602

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q603

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q604

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q812

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q813

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q816

CVTKSA992FTA

PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD 1

.....5 Q818

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q819

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q820

CVTKSC1845FTA

NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSC1845FTA 1

.....5 Q961

HVTKTA1024YT

T.R KTA1024-Y-AT/P 1

.....5 R501 CRD20TJ433T RES, CARBON(1/5W,43Kohm,J) 43K OHM 1/5W J 1

.....5 R502 CRD20TJ433T RES, CARBON(1/5W,43Kohm,J) 43K OHM 1/5W J 1

.....5 R504 CRD20TJ433T RES, CARBON(1/5W,43Kohm,J) 43K OHM 1/5W J 1

.....5 R505 CRD20TJ433T RES, CARBON(1/5W,43Kohm,J) 43K OHM 1/5W J 1

.....5 R506 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R507 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

Harman Kardon

AVR 151 Service Manual

Page 31 of 131
