AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.....5 R508 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R509 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R511 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R512 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R513 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R514 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R516 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R517 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R518 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R519 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R521 CRD20TJ471T RES, CARBON(1/5W,470ohm,J) 1

.....5 R522 CRD20TJ471T RES, CARBON(1/5W,470ohm,J) 1

.....5 R523 CRD20TJ471T RES, CARBON(1/5W,470ohm,J) 1

.....5 R524 CRD20TJ471T RES, CARBON(1/5W,470ohm,J) 1

.....5 R531 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R532 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R533 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R534 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R536 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R537 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R538 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R539 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R541 CRD20TJ271T RES, CARBON(1/5W,270ohm,J) 1

.....5 R542 CRD20TJ271T RES, CARBON(1/5W,270ohm,J) 1

.....5 R543 CRD20TJ271T RES, CARBON(1/5W,270ohm,J) 1

.....5 R544 CRD20TJ271T RES, CARBON(1/5W,270ohm,J) 1

.....5 R556 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R557 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R558 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R559 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R561 CRD20TJ242T RES, CARBON(1/5W,2.4Kohm,J) 1

.....5 R562 CRD20TJ242T RES, CARBON(1/5W,2.4Kohm,J) 1

.....5

R563 CRD20TJ242T RES, CARBON(1/5W,2.4Kohm,J) 1

.....5 R564 CRD20TJ242T RES, CARBON(1/5W,2.4Kohm,J) 1

.....5 R566 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R567 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R568 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R569 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R571 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R572 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R573 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R574 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R576 CRD20TJ100T RES, CARBON(1/5W,10ohm,J) 1

.....5 R577 CRD20TJ100T RES, CARBON(1/5W,10ohm,J) 1

.....5 R578 CRD20TJ100T RES, CARBON(1/5W,10ohm,J) 1

.....5 R579 CRD20TJ100T RES, CARBON(1/5W,10ohm,J) 1

.....5 R581 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R582 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R583 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R584 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R586 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R587 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R588 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R589 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R591 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R592 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R593 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R594 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R596 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R597 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R598 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R599 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R601 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R602 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R603 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R604 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R606 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R607 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R608 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R609 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R611 CRD20TJ100T RES, CARBON(1/5W,10ohm,J) 1

.....5 R631 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R632 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R633 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R634 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R636 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R637 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R638 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R639 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R646 CRD25FJ3R3T RES , CARBON 1

.....5 R647 CRD25FJ3R3T RES , CARBON 1

.....5 R648 CRD25FJ3R3T RES , CARBON 1

.....5 R649 CRD25FJ3R3T RES , CARBON 1

.....5 R651 CRD25FJ3R3T RES , CARBON 1

.....5 R652 CRD25FJ3R3T RES , CARBON 1

.....5 R653 CRD25FJ3R3T RES , CARBON 1

.....5 R654 CRD25FJ3R3T RES , CARBON 1

.....5 R666 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R667 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R668 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R669 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

Harman Kardon

AVR 151 Service Manual
