AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.....5 R671 CRD20TJ472T RES, CARBON(1/5W,4.7Kohm,J) 1

.....5 R672 CRD20TJ472T RES, CARBON(1/5W,4.7Kohm,J) 1

.....5 R673 CRD20TJ472T RES, CARBON(1/5W,4.7Kohm,J) 1

.....5 R674 CRD20TJ472T RES, CARBON(1/5W,4.7Kohm,J) 1

.....5 R676 CRD25TJ182T RES, CARBON(1/4W,1.8Kohm,J) 1

.....5 R677 CRD25TJ182T RES, CARBON(1/4W,1.8Kohm,J) 1

.....5 R678 CRD25TJ182T RES, CARBON(1/4W,1.8Kohm,J) 1

.....5 R679 CRD25TJ182T RES, CARBON(1/4W,1.8Kohm,J) 1

.....5 R681 CRD20TJ562T RES, CARBON(1/5W,5.6Kohm,J) 1

.....5 R682 CRD20TJ562T RES, CARBON(1/5W,5.6Kohm,J) 1

.....5 R683 CRD20TJ562T RES, CARBON(1/5W,5.6Kohm,J) 1

.....5 R684 CRD20TJ562T RES, CARBON(1/5W,5.6Kohm,J) 1

.....5 R696 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R697 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R698 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R699 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R711

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R712

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R713

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R714

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R715

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R716

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R717

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R718

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R719

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R720

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R721

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R722

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R723

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R724

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R725

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R726

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5

R727

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R728

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R729

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R730

CRG2SANJR47RT

RES, M-OXIDE FILM(2W/0.47ohm) 1

.....5 R771 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R772 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R773 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R774 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R776 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R781 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R782 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R783 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R784 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R786 CRD20TJ750T RES, CARBON(1/5W,75ohm,J) 1

.....5 R803 CRD20TJ562T RES, CARBON(1/5W,5.6Kohm,J) 1

.....5 R805 CRD20TJ472T RES, CARBON(1/5W,4.7Kohm,J) 1

.....5 R808 CRD25TJ182T RES, CARBON(1/4W,1.8Kohm,J) 1

.....5 R812 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R813 CRD25TJ470T RES, CARBON(1/4W,47ohm,J) 1

.....5 R817 CRD25FJ3R3T RES , CARBON 1

.....5 R818 CRD25FJ3R3T RES , CARBON 1

.....5 R821 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R822 CRD25FJ180T RES , CARBON (18 OHM) NONFLAMMABLE 1

.....5 R830 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R831 CRD20TJ223T RES, CARBON(1/5W,22Kohm,J) 1

.....5 R834 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R835 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R836 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R837 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R842 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R843 CRD20TJ561T RES, CARBON(1/5W,560ohm,J) 1

.....5 R848 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R850 CRD20TJ242T RES, CARBON(1/5W,2.4Kohm,J) 1

.....5 R852 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R853 CRD20TJ152T RES, CARBON(1/5W,1.5Kohm,J) 1

.....5 R856 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R857 CRD20TJ101T RES, CARBON(1/5W,100ohm,J) 1

.....5 R860 CRD20TJ271T RES, CARBON(1/5W,270ohm,J) 1

.....5 R862 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R870 CRD20TJ433T RES, CARBON(1/5W,43Kohm,J) 43K OHM 1/5W J 1

.....5 R872 CRD20TJ471T RES, CARBON(1/5W,470ohm,J) 1

.....5 R875 CRD20TJ361T RES, CARBON(1/5W,360ohm,J) 360 OHM 1/5W J 1

.....5 R877 CRD20TJ361T RES, CARBON(1/5W,360ohm,J) 360 OHM 1/5W J 1

.....5 R878 CRD20TJ361T RES, CARBON(1/5W,360ohm,J) 360 OHM 1/5W J 1

.....5 R879 CRD20TJ361T RES, CARBON(1/5W,360ohm,J) 360 OHM 1/5W J 1

.....5 R880 CRD20TJ361T RES, CARBON(1/5W,360ohm,J) 360 OHM 1/5W J 1

.....5 R883 CRD20TJ122T RES, CARBON(1/5W,1.2Kohm,J) 1

.....5 R885 CRD20TJ122T RES, CARBON(1/5W,1.2Kohm,J) 1

.....5 R886 CRD20TJ122T RES, CARBON(1/5W,1.2Kohm,J) 1

.....5 R887 CRD20TJ122T RES, CARBON(1/5W,1.2Kohm,J) 1

.....5 R888 CRD20TJ122T RES, CARBON(1/5W,1.2Kohm,J) 1

.....5 R891 CRD20TJ391T RES, CARBON(1/5W,390ohm,J) 1

.....5 R893 CRD20TJ391T RES, CARBON(1/5W,390ohm,J) 1

.....5 R894 CRD20TJ391T RES, CARBON(1/5W,390ohm,J) 1

.....5 R896 CRD20TJ391T RES, CARBON(1/5W,390ohm,J) 1

.....5 R897 CRD20TJ391T RES, CARBON(1/5W,390ohm,J) 1

.....5 R908 CRD20TJ333T RES, CARBON(1/5W,33Kohm,J) 1

.....5 R909 CRD20TJ333T RES, CARBON(1/5W,33Kohm,J) 1

.....5 R941 CRD20TJ103T RES, CARBON(1/5W,10Kohm,J) 1

Harman Kardon

AVR 151 Service Manual

Page 33 of 131
