AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

.....5 R942 CRD20TJ103T RES, CARBON(1/5W,10Kohm,J) 1

.....5 R944 CRD20TJ103T RES, CARBON(1/5W,10Kohm,J) 1

.....5 R946 CRD20TJ103T RES, CARBON(1/5W,10Kohm,J) 1

.....5 R947 CRD20TJ103T RES, CARBON(1/5W,10Kohm,J) 1

.....5 R951 CRD20TJ1R0T RES, CARBON(1/5W,1ohm,J) 1

.....5 R954 CRD20TJ102T RES, CARBON(1/5W,1Kohm,J) 1

.....5 R955 CRD20TJ564T RES, CARBON(1/5W,560Kohm,J) 1

.....5 R961 CRD20TJ331T RES, CARBON(1/5W,330ohm,J) 1

.....5 R962 CRD20TJ273T RES, CARBON(1/5W,27Kohm,J) 1

.....5 R990

CRG1SANJ100RT

RES, M-OXIDE FILM(1W/10ohm) 1

.....5 R993

CRG1SANJ100RT

RES, M-OXIDE FILM(1W/10ohm) 1

.....5 R995

CRG1SANJ100RT

RES, M-OXIDE FILM(1W/10ohm) 1

.....5 R997

CRG1SANJ100RT

RES, M-OXIDE FILM(1W/10ohm) 1

.....5 R999

CRG1SANJ100RT

RES, M-OXIDE FILM(1W/10ohm) 1

.....5 VR82

CVN12A221B03T

RES , SEMI FIXED (220 OHM) NVZ6TLTAB221 1

.....5 VR84

CVN12A221B03T

RES , SEMI FIXED (220 OHM) NVZ6TLTAB221 1

.....5 VR85

CVN12A221B03T

RES , SEMI FIXED (220 OHM) NVZ6TLTAB221 1

.....5 VR86

CVN12A221B03T

RES , SEMI FIXED (220 OHM) NVZ6TLTAB221 1

.....5 VR87

CVN12A221B03T

RES , SEMI FIXED (220 OHM) NVZ6TLTAB221 1

....4 CMYAVR1510 HEAT SINK ASS'Y 1

.....5 CHD1A012R SCREW , SPECIAL 15

.....5 CHD4A012R SCREW , SPECIAL 1

.....5 CMD1A802 BRACKET,H/S PCB 2

.....5 CMD1A810 BRACKET , PCB 2

.....5 CMY1A388 HEAT SINK AVR1510 1

.....5 CTB3+8JR SCREW 00M51260308M0 8

.....5 Q652 CVT2SB1559P T.R , POWER 2SB1559P 1

.....5 Q653 CVT2SB1559P T.R , POWER 2SB1559P 1

.....5 Q654 CVT2SB1559P T.R , POWER 2SB1559P 1

.....5 Q657 CVT2SD2389P T.R , POWER 2SD2389P 1

.....5 Q658 CVT2SD2389P T.R , POWER 2SD2389P 1

.....5 Q659 CVT2SD2389P T.R , POWER 2SD2389P 1

.....5

Q660 CVT2SD2389P T.R , POWER 2SD2389P 1

.....5 Q661 CVT2SB1559P T.R , POWER 2SB1559P 1

.....5 Q803 CVT2SD2389P T.R , POWER 2SD2389P 1

.....5 Q804 CVT2SB1559P T.R , POWER 2SB1559P 1

.....5 Q852

HVTKTD600KGR

T.R , BIAS KTD600K-Y-U/PH 1

.....5 Q854

HVTKTD600KGR

T.R , BIAS KTD600K-Y-U/PH 1

.....5 Q855

HVTKTD600KGR

T.R , BIAS KTD600K-Y-U/PH 1

.....5 Q856

HVTKTD600KGR

T.R , BIAS KTD600K-Y-U/PH 1

.....5 Q857

HVTKTD600KGR

T.R , BIAS KTD600K-Y-U/PH 1

....4 BK90 CMD1A629 BRACKET , PCB 1

....4 BK91 CMD1A629 BRACKET , PCB 1

....4 BN60

CWB3FE03320UZ

WIRE ASS'Y (3P, 320mm) 1

....4 BN61

CWB1B0031507H

WIRE ASS'Y (3P, 2.0mm, 150mm) 1

....4 CN54 CJP17GA115ZY WAFER, FFC(17P-1.25mm, STRAIGHT) 12511HS-17 1

....4 CN55 CJP27GA115ZY WAFER, FFC(27P-1.25mm, STRAIGHT) 12511HS-27 1

....4 CN61 CJP02GA01ZY WAFER/STRAIGHT/2.5mm/2P YMW025-02R 1

....4 CN62 CJP02GA01ZY WAFER/STRAIGHT/2.5mm/2P YMW025-02R 1

....4 CN63 CJP02GA01ZY WAFER/STRAIGHT/2.5mm/2P YMW025-02R 1

....4 CN64 CJP02GA01ZY WAFER/STRAIGHT/2.5mm/2P YMW025-02R 1

....4 CN66 CJP02GA01ZY WAFER/STRAIGHT/2.5mm/2P YMW025-02R 1

....4 C915

CCET50VLP222NC

CAP , ELECT (2200uF/50V, 85'C), 22X26 1

....4 C916

CCET50VLP222NC

CAP , ELECT (2200uF/50V, 85'C), 22X26 1

....4 ET01

CWE5202080A

WIRE ASS'Y (1P, 80MM,BLK,#22) 1

....4 JK312 CJJ4P014W JACK , IN/OUT RCA-401DA(II)-05 1

....4 JK90 CJJ4M040Z JACK , BOARD (SW) RCA-107B-01 1

....4 JK91 CJJ5R020Z TERMINAL , SPEAKER (PUSH TYPE) 1

....4 JK92 CJJ5P020Z TERMINAL , SPEAKER JB-405E-09 1

....4 L501 CLEY0R5KAK COIL , SPEAKER(0.5uH) 0.5UH K 1

....4 L502 CLEY0R5KAK COIL , SPEAKER(0.5uH) 0.5UH K 1

....4 L503 CLEY0R5KAK COIL , SPEAKER(0.5uH) 0.5UH K 1

....4 L504 CLEY0R5KAK COIL , SPEAKER(0.5uH) 0.5UH K 1

....4 L506 CLEY0R5KAK COIL , SPEAKER(0.5uH) 0.5UH K 1

....4 Q858 HVTKTA1360Y T.R , PRE DRIVE KTA1360-Y-U/PH 1

....4 Q871 HVTKTA1360Y T.R , PRE DRIVE KTA1360-Y-U/PH 1

....4 Q872 HVTKTA1360Y T.R , PRE DRIVE KTA1360-Y-U/PH 1

....4 Q874 HVTKTA1360Y T.R , PRE DRIVE KTA1360-Y-U/PH 1

....4 Q876 HVTKTA1360Y T.R , PRE DRIVE KTA1360-Y-U/PH 1

....4 Q881 HVTKTC3423Y T.R , PRE DRIVE KTC3423-Y-U/PH 1

....4 Q882 HVTKTC3423Y T.R , PRE DRIVE KTC3423-Y-U/PH 1

....4 Q883 HVTKTC3423Y T.R , PRE DRIVE KTC3423-Y-U/PH 1

....4 Q884 HVTKTC3423Y T.R , PRE DRIVE KTC3423-Y-U/PH 1

....4 Q886 HVTKTC3423Y T.R , PRE DRIVE KTC3423-Y-U/PH 1

....4 R937 CRF5EKR10HS RES , CEMENT (SMALL SIZE) 1

....4 R938 CRF5EKR10HS RES , CEMENT (SMALL SIZE) 1

....4 TUN1

CNVMW104MV1R78

MODULE , TUNER (AM/FM WITH RDS) 1

...3 COP12509I AVR151/230 SMPS PCB ASS'Y 1

......6 C903 CCUC1H474KC CAP, CHIP(2012, 50V/0.47uF) 1

......6 C904 CCUC1H105KC CAP, CHIP(2012, 50V/1uF) 1

......6 C905 CCUP3A102KC CAP, CHIP(3216, 1KV/1000pF, X7R) 1

......6 C906 CCUC1H222KC CAP, CHIP(2012, 50V/2200pF) 1

......6 C907 CCUC1H470JA CAP, CHIP(2012, 50V/47pF) 1

......6 C908 CCUP3A221JA CAP, CHIP(3216, 1KV/220pF, X7R) 1

......6 C909 CCUC1H821JA CAP, CHIP(2012, 50V/820pF, NPO) 1

......6 C910 CCUP3A222KC CAP, CHIP(3216, 1KV/2200pF, X7R) 1

......6 C912 CCUP3A470JA CAP, CHIP(3216, 1KV/47pF, X7R) 1

......6 C913 CCUC1E225KC CAP, CHIP(2012, 25V/2.2uF, X7R) 1

......6 C914 CCUC1H472KC CAP, CHIP(2012, 50V/4700pF) 1

......6 C915 CCUC1H105KC CAP, CHIP(2012, 50V/1uF) 1

......6 C917 CCUC1H472KC CAP, CHIP(2012, 50V/4700pF) 1

Harman Kardon

AVR 151 Service Manual

Page 34 of 131
