AVR 151, 5.1CH RECEIVER, bill of materials
Level Ref# Component Description Drawing No REQ-Qty
......6 C919 CCUP3A470JA CAP, CHIP(3216, 1KV/47pF, X7R) 1
......6 C923 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C924 CCUC1H222KC CAP, CHIP(2012, 50V/2200pF) 1
......6 C925 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C926 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C927 CCUC1H105KC CAP, CHIP(2012, 50V/1uF) 1
......6 C934 CCUC1H105KC CAP, CHIP(2012, 50V/1uF) 1
......6 C945 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C956 CCUP3A102KC CAP, CHIP(3216, 1KV/1000pF, X7R) 1
......6 C957 CCUP3A102KC CAP, CHIP(3216, 1KV/1000pF, X7R) 1
......6 C958 CCUC1H103KC CAP, CHIP(2012, 50V/0.01uF) 1
......6 C959 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C960 CCUC1H103KC CAP, CHIP(2012, 50V/0.01uF) 1
......6 C961 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C962 CCUC1H103KC CAP, CHIP(2012, 50V/0.01uF) 1
......6 C963 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C964 CCUC1H103KC CAP, CHIP(2012, 50V/0.01uF) 1
......6 C967 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C968 CCUC1H103KC CAP, CHIP(2012, 50V/0.01uF) 1
......6 C969 CCUC1H224KC CAP, CHIP(2012, 50V/0.22uF) 1
......6 C970 CCUC1H223KC CAP, CHIP(2012, 50V/0.022uF, X7R) 1
......6 C971 CCUC1H224KC CAP, CHIP(2012, 50V/0.22uF) 1
......6 C972 CCUC1H223KC CAP, CHIP(2012, 50V/0.022uF, X7R) 1
......6 C973 CCUC1H224KC CAP, CHIP(2012, 50V/0.22uF) 1
......6 C974 CCUC1H223KC CAP, CHIP(2012, 50V/0.022uF, X7R) 1
......6 C975 CCUC1H224KC CAP, CHIP(2012, 50V/0.22uF) 1
......6 C976 CCUC1H223KC CAP, CHIP(2012, 50V/0.022uF, X7R) 1
......6 C977 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C978 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 C979 CCUC1H104KC CAP, CHIP(2012, 50V/0.1uF) 1
......6 D901 CVDS1M DIODE, SURFACE MOUNT RECTIFIER(1000V/1A) 1
......6 D902 CVDS1M DIODE, SURFACE MOUNT RECTIFIER(1000V/1A) 1
......6
D903 CVDUS1M DIODE , ULTRA FAST RECTIFIER 1
......6 D904 CVDUS1M DIODE , ULTRA FAST RECTIFIER 1
......6 D906 CVDUS1M DIODE , ULTRA FAST RECTIFIER 1
......6 D907
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D908
CVDMM1Z24H
DIODE , ZENER(24V/0.5W, SOD-123) 1
......6 D909
CVDMM1Z20H
DIODE , ZENER(20V/0.5W, SOD-123) 1
......6 D911 CVDUS1M DIODE , ULTRA FAST RECTIFIER 1
......6 D912
CVDMM1Z27H
DIODE , ZENER(27V/0.5W, SOD-123) 1
......6 D913 CVDS1M DIODE, SURFACE MOUNT RECTIFIER(1000V/1A) 1
......6 D914
CVDMM1Z18H
DIODE , ZENER(18V/0.5W, SOD-123) 1
......6 D917
CVDMM1Z16H
DIODE , ZENER(16V/0.5W, SOD-123) 1
......6 D918
CVDMM1Z16H
DIODE , ZENER(16V/0.5W, SOD-123) 1
......6 D922
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D924
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D925
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D926
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D927
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D929
CVDMM1Z12H
DIODE , ZENER(12V/0.5W, SOD-123) 1
......6 D932 CVDS1M DIODE, SURFACE MOUNT RECTIFIER(1000V/1A) 1
......6 D935
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D936
CVD1N4448W
DIODE , FAST SWITCHING(0.5W, SOD-123) 1
......6 D944 CVDUS1M DIODE , ULTRA FAST RECTIFIER 1
......6 D950
CVDMM1Z15H
DIODE , ZENER(15V/0.5W, SOD-123) 1
......6 IC93 CVIICE2QS02G I.C , PWM CONTROLLER(PG-DSO-8) 1
......6 IC94
CVIKA431SAMF2
I.C , SHUNT REGULATOR(SOT-23F) 1
......6 IC95
CVIKA431SAMF2
I.C , SHUNT REGULATOR(SOT-23F) 1
......6 IC96
CVIKA431SAMF2
I.C , SHUNT REGULATOR(SOT-23F) 1
......6 L922 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
......6 L923 CLZ9Z014Z FERRITE CHIP BEAD(4516/60R) HCB4516KF-600T60 1
......6 Q909 CVTRT1N141C T.R,RT1N141C(10K-10K) RT1N141C 1
......6 Q915 CVTRT1N141C T.R,RT1N141C(10K-10K) RT1N141C 1
......6 Q916 CVTRT1N141C T.R,RT1N141C(10K-10K) RT1N141C 1
......6 R901 CRJ18AJ392T RES, CHIP(2012/5%/3.9Kohm) 0805 5% 1
......6 R902 CRJ18AJ153T RES, CHIP(2012/5%/15Kohm) 0805 5% 1
......6 R904 CRJ14CJ0R0T RES, CHIP(3216/5%/0ohm) 1
......6 R906 CRJ18AJ390T RES, CHIP(2012/5%/39ohm) 1
......6 R907 CRJ01HJ683T RES, CHIP(6432/5%/68Kohm) 1
......6 R910 CRJ18AJ330T RES, CHIP(2012/5%/33ohm) 1
......6 R911 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1
......6 R912 CRJ18AJ112T RES, CHIP(2012/5%/1.1Kohm) 1
......6 R915 CRJ18AJ683T RES, CHIP(2012/5%/68Kohm) 0805 5% 1
......6 R916 CRJ18AJ153T RES, CHIP(2012/5%/15Kohm) 0805 5% 1
......6 R918 CRJ18AJ203T RES, CHIP(2012/5%/20Kohm) 1
......6 R919 CRJ18AJ103T RES, CHIP(2012/5%/10Kohm) 0805 5% 1
......6 R921 CRJ14CF5602T RES, CHIP(3216/1%/56Kohm) 1
......6 R922 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1
......6 R923 CRJ18AJ102T RES, CHIP(2012/5%/1Kohm) 0805 5% 1
......6 R924 CRJ14CJ125T RES, CHIP(3216/5%/1.2Mohm) 1
......6 R925 CRJ14CJ125T RES, CHIP(3216/5%/1.2Mohm) 1
......6 R926 CRJ14CJ125T RES, CHIP(3216/5%/1.2Mohm) 1
......6 R927 CRJ14CJ125T RES, CHIP(3216/5%/1.2Mohm) 1
......6 R928 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1
......6 R929 CRJ14CJ125T RES, CHIP(3216/5%/1.2Mohm) 1
......6 R930 CRJ18AF6802T RES, CHIP(2012/1%/68Kohm) 1
......6 R931 CRJ18AJ824T RES, CHIP(2012/5%/820Kohm) 1
......6 R932 CRJ14CJ4R7T RES, CHIP(3216/5%/4.7ohm) 3216 1
......6 R933 CRJ18AJ181T RES, CHIP(2012/5%/180ohm) 0805 5% 1
......6 R934 CRJ18AJ561T RES, CHIP(2012/5%/560ohm) 0805 5% 1
......6 R935 CRJ18AJ220T RES, CHIP(2012/5%/22ohm) 0805 5% 1
