AVR 151, 5.1CH RECEIVER, bill of materials

Level Ref# Component Description Drawing No REQ-Qty

......6 R936 CRJ18AJ102T RES, CHIP(2012/5%/1Kohm) 0805 5% 1

......6 R937 CRJ18AJ102T RES, CHIP(2012/5%/1Kohm) 0805 5% 1

......6 R938 CRJ18AJ561T RES, CHIP(2012/5%/560ohm) 0805 5% 1

......6 R939 CRJ18AJ470T RES, CHIP(2012/5%/47ohm) 0805 5% 1

......6 R940 CRJ18AJ153T RES, CHIP(2012/5%/15Kohm) 0805 5% 1

......6 R941 CRJ18AJ622T RES, CHIP(2012/5%/6.2Kohm) 1

......6 R942 CRJ18AJ222T RES, CHIP(2012/5%/2.2Kohm) 0805 5% 1

......6 R943 CRJ18AJ622T RES, CHIP(2012/5%/6.2Kohm) 1

......6 R944 CRJ18AJ472T RES, CHIP(2012/5%/4.7Kohm) 0805 5% 1

......6 R945 CRJ18AJ561T RES, CHIP(2012/5%/560ohm) 0805 5% 1

......6 R946 CRJ18AF1002T RES, CHIP(2012/1%/10Kohm) 1

......6 R947 CRJ18AF1002T RES, CHIP(2012/1%/10Kohm) 1

......6 R948 CRJ14CJ0R0T RES, CHIP(3216/5%/0ohm) 1

......6 R950 CRJ18AJ224T RES, CHIP(2012/5%/220Kohm) 1

......6 R952 CRJ01HJ101T RES, CHIP(6432/5%/100ohm) 1

......6 R953 CRJ18AF1502T RES, CHIP(2012/1%/15Kohm) 1

......6 R954 CRJ18AJ472T RES, CHIP(2012/5%/4.7Kohm) 0805 5% 1

......6 R955 CRJ14CF5602T RES, CHIP(3216/1%/56Kohm) 1

......6 R956 CRJ18AJ473T RES, CHIP(2012/5%/47Kohm) 0805 5% 1

......6 R957 CRJ18AJ181T RES, CHIP(2012/5%/180ohm) 0805 5% 1

......6 R958 CRJ18AF1002T RES, CHIP(2012/1%/10Kohm) 1

......6 R959 CRJ18AF5601T RES, CHIP(2012/1%/5.6Kohm) 1

......6 R960 CRJ01HJ752T RES, CHIP(6432/5%/7.5Kohm) 1

......6 R961 CRJ18AJ103T RES, CHIP(2012/5%/10Kohm) 0805 5% 1

......6 R962 CRJ18AF2002T RES, CHIP(2012/1%/20Kohm) 1

......6 R963 CRJ14CJ0R0T RES, CHIP(3216/5%/0ohm) 1

......6 R966 CRJ18AJ220T RES, CHIP(2012/5%/22ohm) 0805 5% 1

......6 R967 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1

......6 R968 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R969 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R970 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1

......6 R971 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1

......6

R972 CRJ18AJ100T RES, CHIP(2012/5%/10ohm) 00200-0001 1

......6 R973 CRJ01HJ221T RES, CHIP(6432/5%/220ohm) 1

......6 R974 CRJ14CJ154T RES, CHIP(3216/5%/150Kohm) 1

......6 R975 CRJ14CJ154T RES, CHIP(3216/5%/150Kohm) 1

......6 R976 CRJ14CJ154T RES, CHIP(3216/5%/150Kohm) 1

......6 R977 CRJ18AF1503T RES, CHIP(2012/1%/150Kohm) 1

......6 R978 CRJ01HJ221T RES, CHIP(6432/5%/220ohm) 1

......6 R979 CRJ14CJ474T RES, CHIP(3216/5%/470Kohm) 1

......6 R980 CRJ14CJ474T RES, CHIP(3216/5%/470Kohm) 1

......6 R981 CRJ14CJ474T RES, CHIP(3216/5%/470Kohm) 1

......6 R982 CRJ14CJ474T RES, CHIP(3216/5%/470Kohm) 1

......6 R984 CRJ18AJ470T RES, CHIP(2012/5%/47ohm) 0805 5% 1

......6 R985 CRJ18AJ182T RES, CHIP(2012/5%/1.8Kohm) 1

......6 R986 CRJ18AJ561T RES, CHIP(2012/5%/560ohm) 0805 5% 1

......6 R988 CRJ18AJ0R0T RES, CHIP(2012/5%/0ohm) 00200-0000 1

......6 R989 CRJ18AJ182T RES, CHIP(2012/5%/1.8Kohm) 1

......6 R990 CRJ01HJ100T RES , CHIP 2515 5% 100HM 1

......6 R991 CRJ18AJ102T RES, CHIP(2012/5%/1Kohm) 0805 5% 1

......6 R992 CRJ14CJ0R0T RES, CHIP(3216/5%/0ohm) 1

......6 R993 CRJ01HJ752T RES, CHIP(6432/5%/7.5Kohm) 1

......6 R994 CRJ01HJ361T RES, CHIP(6432/5%/360ohm) 1

......6 R995 CRJ01HJ361T RES, CHIP(6432/5%/360ohm) 1

......6 R996 CRJ18AJ470T RES, CHIP(2012/5%/47ohm) 0805 5% 1

......6 R997 CRJ14CF5602T RES, CHIP(3216/1%/56Kohm) 1

......6 R999 CRJ14CF5602T RES, CHIP(3216/1%/56Kohm) 1

.....5 C911 CCKT3A102KBL CAP, CERAMIC(1kV/1000pF/K) EKR3A102K05FK5 1

.....5 C918

CCEA1HH100TCS

CAP, ELECT(50V/10uF),105'C 1

.....5 C920

CCEA1HH470TCS

CAP, ELECT(50V/47uF),105'C 1

.....5 C921

CCEA1HH220TCS

CAP, ELECT(50V/22uF),105'C 1

.....5 C929

CCEA0JH471TCS

CAP, ELECT(6.3V/470uF),105'C 1

.....5 C932

CCEA1HH470TCS

CAP, ELECT(50V/47uF),105'C 1

.....5 C944

CCEA0JH102TCS

CAP, ELECT(6.3V/1000uF),105'C 1

.....5 C949

CCEA2AH100TCS

CAP, ELECT(100V/10uF),105'C 1

.....5 C953

CCEA1EH101TCS

CAP, ELECT(25V/100uF),105'C 1

.....5 C955

CCEA1HH220TCS

CAP, ELECT(50V/22uF),105'C 1

.....5 C984

CCEA0JH471TCS

CAP, ELECT(6.3V/470uF),105'C 1

.....5 D910 HVDUF4007T DIODE , SCHOTTKY UF4007 1

.....5 D916 CVDZJ20BT DIODE , ZENER ,1/2W, 20V ZJ20BT(26MM T/B) 1

.....5 D919 HVD1N4007T DIODE 1N4007T 1

.....5 D920 HVDUF4004T DIODE , SCHOTTKY UF4004 1

.....5 D921 HVD11EQ06T DIODE , SCHOTTKY (60V/1A) 11EQ06 1

.....5 D928 CVDZJ20BT DIODE , ZENER ,1/2W, 20V ZJ20BT(26MM T/B) 1

.....5 D933 CVDSF26 DIODE , SUPER FAST RECTIFIER 1

.....5 D937 CVDSF26 DIODE , SUPER FAST RECTIFIER 1

.....5 D943 HVDUF4004T DIODE , SCHOTTKY UF4004 1

.....5 ET91 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 ET92 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 ET93 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 ET95 CJT1A026 PLATE , EARTH(TRONIC ELECTRONICS) 1

.....5 FH91 KJCFC5S HOLDER , FUSE 1

.....5 FH92 KJCFC5S HOLDER , FUSE 1

.....5 IC99 CVIL78L24AB IC, REGULATOR ( 24V, TO-92L ) L78L24ABZ-TR 1

.....5 Q902 HVTKSA708YT T.R KSA708-YTA 1

.....5 Q903 HVTKSA708YT T.R KSA708-YTA 1

.....5 Q914 HVTKSA708YT T.R KSA708-YTA 1

.....5 RX93 CRO50TJ155T RES , SURGE ,(1.5M OHM, 5%, 1/2W, PRC TYPE) 1

....4 C4B120122 TUBE , UL 0.02

....4 BD91 CLZ9H002Z BEAD , CORE(100MHz MIN 120ohm) 1

....4 BN65

CWB1C01525047

WIRE ASSY (LOCK, 15P, 250mm, 2.0mm) 1
