4
AVR 1650/AVR 165 Front-Panel Controls
Front-Panel Controls
Power
Indicator
Message
Display
Volume
Knob
Surround Mode
Select Buttons
Set
Button
IR
Sensor
Power
Button
Left/Right
Buttons
Headphone Jack/
EzSet/EQ Mic
Connector
Source Select
Buttons
Tuning Mode
Button
Digital Input
Button
Surround-Mode
Category Button
Up/Down Buttons/
Tuning Buttons
USB
Port
Aux Analog
Audio Input
Connector
Channel
Level Control
Button

Table of Contents

Other manuals for Harman Kardon AVR 165

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Harman Kardon AVR 165 and is the answer not in the manual?

Harman Kardon AVR 165 Specifications

General IconGeneral
Receiver type-
Frequency range20 - 20000 Hz
RMS rated power- W
Audio output channels5.1 channels
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.07 %
Power output per channel (20-20KHz@8 Ohm)95 W
DisplayLCD
Product colorBlack
Audio decodersDolby Digital Plus, Dolby TrueHD, DTS, DTS-HD
Handheld remote controlNo
Apple docking compatibilityNot supported
HDMI in4
Component video (YPbPr/YCbCr) in1
Connectivity technologyWired
AM band range520 - 1620 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
3DYes
AC input voltage230 V
AC input frequency50 - 60 Hz
Power consumption (typical)280 W
Weight and Dimensions IconWeight and Dimensions
Depth385 mm
Width440 mm
Height165 mm
Weight9100 g
