Harman Kardon AVR 235 Service Manual

Ref# Component Description 1 Description 2 Qty
CTB3+10G SCREW 37
CTB3+16GFZ SCREW 2
CTWS3+10G SCREW 1
KHR301 CLAMPER 3
CB72 CWC1B2A32A250B CABLE , CARD 1
Ref# Component Description 1 Description 2 Qty
COP11746F MAIN PCB ASS'Y 1
C501 HCEA1VH100T CAP , ELECT 10UF 35V 1
C502 HCEA1VH100T CAP , ELECT 10UF 35V 1
C503 HCEA1VH100T CAP , ELECT 10UF 35V 1
C504 HCEA1VH100T CAP , ELECT 10UF 35V 1
C505 HCEA1VH100T CAP , ELECT 10UF 35V 1
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V KB 1
C507 CCKT1H331KB CAP , CERAMIC 330PF 50V KB 1
C508 CCKT1H331KB CAP , CERAMIC 330PF 50V KB 1
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V KB 1
C510 CCKT1H331KB CAP , CERAMIC 330PF 50V KB 1
C561 HCEA1CH101T CAP , ELECT 100UF 16V 1
C562 HCEA1CH101T CAP , ELECT 100UF 16V 1
C563 HCEA1CH101T CAP , ELECT 100UF 16V 1
C564 HCEA1CH101T CAP , ELECT 100UF 16V 1
C565 HCEA1CH101T CAP , ELECT 100UF 16V 1
C566 HCEA1CH101T CAP , ELECT 100UF 16V 1
C567 HCEA1CH101T CAP , ELECT 100UF 16V 1
C568 HCEA1CH101T CAP , ELECT 100UF 16V 1
C569 HCEA1CH101T CAP , ELECT 100UF 16V 1
C570 HCEA1CH101T CAP , ELECT 100UF 16V 1
C571 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1
C572 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1
C573 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1
C574 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1
C575 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V JC 1
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V JC 1
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V JC 1
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V JC 1
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V JC 1
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V JC 1
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V JC 1
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V JC 1
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V JC 1
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V JC 1
C681 HCEA1HH100T CAP , ELECT 10UF 50V 1
C682 HCEA1HH100T CAP , ELECT 10UF 50V 1
C683 HCEA1HH100T CAP , ELECT 10UF 50V 1
C684 HCEA1HH100T CAP , ELECT 10UF 50V 1
C685 HCEA1HH100T CAP , ELECT 10UF 50V 1
C721 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C722 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C723 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C724 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C725 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C726 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C727 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C728 CCKT1H221KB CAP , MYLAR 220PF 50V KB 1
C801 HCEA1HH100T CAP , ELECT 10UF 50V 1
C802 HCEA1HH100T CAP , ELECT 10UF 50V 1
Front PCB assy
MAIN PCB Assy
Harman Consumer Group International HARMAN/KARDON AVR235/230

Harman Kardon AVR 235 Specifications

General

Brand	Harman Kardon
Model	AVR 235
Category	Receiver
Language	English
