Ref# Component Description 1 Description 2 Qty
JK15 CJJ4R037W JACK , BOARD 1
JW21 CWE7202090AA WIRE ASS'Y 1
J103 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0,018
J104 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0,018
L701 KLZ9H001Z BEAD , CORE 1
L702 KLZ9H001Z BEAD , CORE 1
L703 KLZ9H001Z BEAD , CORE 1
R781 CRG2ANJ270H RES , METAL OXIDE FILM 27 OHM 2W J 1
R782 CRG2ANJ330H RES , METAL OXIDE FILM 33 OHM 2W J 1
X701 HOX12288E220CS CRYSTAL 12.288MHZ 1
Ref# Component Description 1 Description 2 Qty
IC71 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN 1
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R702 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1
R703 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R704 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1
R705 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R706 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R707 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R708 CRD20TJ241T RES, CARBON 240OHM 1/5W J 1
R709 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R710 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1
R711 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1
R713 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R714 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1
R715 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R716 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R717 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
R718 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
R719 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
R720 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1
C701 HCEA1AH471T CAP , ELECT 470UF 10V 1
C702 HCEA1AH471T CAP , ELECT 470UF 10V 1
C703 CCKT1H181KB CAP , CERAMIC 180PF 50V KB 1
C704 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1
C705 CCKT1H181KB CAP , CERAMIC 180PF 50V KB 1
C706 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1
C707 CCKT1H101KB CAP , CERAMIC 100PF 50V KB 1
C708 HCEA1CKS101T CAP , ELECT 100UF 50V 1
C709 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1
C711 HCEA1CH101T CAP , ELECT 100UF 16V 1
C712 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z 1
CMC1A111 PLATE , EARTH 1
CMC1A213 PLATE , SHIELD AVR230 1
BN17 KJP12GB143ZP DIP SOCKET 3011 - DR12 - G 1
JK71 HJSTORX179L MODULE , OPTICAL(RX) TORX179L 1
JK72 HJSTORX179L MODULE , OPTICAL(RX) TORX179L 1
JK73 CJJ4S022Z JACK , BOARD 1
JK74 HJSTOTX179L MODULE , OPTICAL(TX) TOTX179L 1
Ref# Component Description 1 Description 2 Qty
COP11747F VIDEO PCB ASS'Y 1
CHG1A218 CUSHION 1,5
BN96 CWB1C908150BM WIRE ASS'Y 1
C401 CCEA1VH100T CAP , ELECT 10UF 35V 1
C402 CCKT1H101KB CAP , CERAMIC 100PF 50V KB 1
C403 HCEA1VH100T CAP , ELECT 10UF 35V 1
DSP / Input PCB ASSY
VIDEO PCB ASSY
DIGITAL INPUT (drawing CUP11747-3)
Harman Consumer Group International HARMAN/KARDON AVR235/230
To Next Page
