Ref# Component Description 1 Description 2 Qty
F903 KJCFC5S HOLDER , FUSE 2
F904 KJCFC5S HOLDER , FUSE 2
F905 KJCFC5S HOLDER , FUSE 2
F906 KJCFC5S HOLDER , FUSE 2
F907 KJCFC5S HOLDER , FUSE 2
T901 CLT5W011ZE TRANS , POWER 230V 1
Ref# Component Description 1 Description 2 Qty
C922 HCEA1EH101T CAP , ELECT 100UF 25V 1
C923 HCEA1EH101T CAP , ELECT 100UF 25V 1
C924 HCEA1EH101T CAP , ELECT 100UF 25V 1
C925 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF 1
C926 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF 1
C927 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V ZF 1
C931 HCEA1HH3R3T CAP , ELECT 3.3UF 50V 1
C928 CCEA1CKR3103E CAP , ELECT 10000UF , 16V 1
C929 CCEA1EH332F CAP , ELECT 3300UF 25V 1
C930 CCEA1EH222E CAP. ELECT. 2200UF 25V 1
D903 HVD1N5819T DIODE , SCHOTTKY 1N5819 1
D904 KVD1N4003ST DIODE 1N4003 1
D905 KVD1N4003ST DIODE 1N4003 1
D906 KVD1N4003ST DIODE 1N4003 1
D907 KVD1N4003ST DIODE 1N4003 1
D915 HVD1SS133MT DIODE 1SS133T-77 1
D916 HVD1SS133MT DIODE 1SS133T-77 1
R912 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R913 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1
R914 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
CN96 KJP08GA01ZM WAFER MOLEX 5267-08A 1
CN98 BJP08GB131ZK WAFER 1
IC91 HVIL7815CP I.C, REGULATOR L7815 1
IC92 HVIL7915CP I.C, REGULATOR L7915 1
IC93 HVIL7805CP I.C, REGULATOR L7805 1
CB13 CWC1C4A13B080B CABLE , CARD 1
CB15 CWC1C4A13B100B CABLE , CARD 1
Ref# Component Description 1 Description 2 Qty
Q995 HVTKRA107MT T.R KRA107M 1
IC95 BVIKP1010B IC, PHOTO COUPLER 1
D951 HVD1SS133MT DIODE 1SS133T-77 1
D952 HVD1SS133MT DIODE 1SS133T-77 1
R951 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R937 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R938 CRD20TJ271T RES , CARBON 270 OHM 1/5W J 1
R915 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1
R916 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1
JK94 CJJ2D008Z JACK , STEREO 1
JK95 CJJ2D008Z JACK , STEREO 1
CN88 KJP04GA19ZM WAFER 1
power supply (drawing CUP11747-4)
Low voltage regulator PCB
Remote IN/OUT
Harman Consumer Group International HARMAN/KARDON AVR235/230
