Ref# Component Description 1 Description 2 Qty
SW91 KST1A010Z SW , TACT CN 1
D101 HVDMTZJ15BT DIODE , ZENER 15V 1/2W 1
D102 HVDMTZJ27BT DIODE , ZENER 27V 1/2W 1
D104 KVD1N4003ST DIODE 1N4003 1
D105 KVD1N4003ST DIODE 1N4003 1
D106 KVD1N4003ST DIODE 1N4003 1
D107 KVD1N4003ST DIODE 1N4003 1
D109 HVDMTZJ12BT DIODE , ZENER 12V 1/2W 1
D111 HVDMTZJ12BT DIODE , ZENER 12V 1/2W 1
R101 KRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J 1
R104 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R105 KRQ1AJR47H RES , FUSE 0.47 OHM 1W J 1
R106 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R107 CRQ1AJR33H RES , FUSE 0.33 OHM 1W J 1
R108 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R109 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1
R110 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R112 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1
R113 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1
C107 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C108 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C109 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1
C110 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1
C111 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C112 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C117 HCEA1HH4R7T CAP , ELECT 4.7UF 50V 1
C118 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C119 HCEA1HH470T CAP , ELECT 47UF 50V 1
C120 HCEA1HH470T CAP , ELECT 47UF 50V 1
C121 CCKT1H103ZF CAP , CERAMIC 0.01UF 50V ZF 1
C122 HCEA1JH101E CAP , ELECT 100UF 63V 1
Ref# Component Description 1 Description 2 Qty
D991 CVDKBU804FMA BRIDGE DIODE ASS'Y KBU804F 1
CMY1A219 HEAT SINK (BRIDGE DIODE) AVR230/330/4600 1
CTB3+12J SCREW 1
HVDKBU804F DIODE , BRIDGE 1
D992 CVDKBU804FMA BRIDGE DIODE ASS'Y KBU804F 1
CMY1A219 HEAT SINK (BRIDGE DIODE) AVR230/330/4600 1
CTB3+12J SCREW 1
HVDKBU804F DIODE , BRIDGE 1
C921 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1
C922 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1
C923 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1
C924 HCQI1H104JZT CAP , MYLAR 0.1UF 50V J 1
C925 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1
C926 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1
C927 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1
C928 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J 1
C931 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1
C932 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1
C933 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1
C934 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1
F903 KBA2C8000TLUZ FUSE 8A 250V 1
F904 KBA2C8000TLUZ FUSE 8A 250V 1
F905 KBA2C6300TLEZ FUSE 6.3A 250V 1
F906 KBA2C6300TLEZ FUSE 6.3A 250V 1
F907 KBA2C4000TLEZ FUSE 4A 250V 1
power supply (drawing CUP11747-5)
power supply (drawing CUP11747-4)
Harman Consumer Group International HARMAN/KARDON AVR235/230
