Ref# Component Description 1 Description 2 Qty
R569 CRD20TJ223T RES , CARBON 22K OHM 1/5W J 1
X501 HOX17734E220C CRYSTAL 17.734MHZ 1
X502 HOX14318E220C CRYSTAL 14.318MHZ 1
IC48 CVIL7805CPNA I.C ASS'Y 1
CMY1A218 HEAT SINK(TR) AVR130/230/330 1
CTB3+8J SCREW 1
HVIL7805CP I.C, REGULATOR 1
IC49 CVIL7905CPNA I.C ASS'Y 1
CMY1A218 HEAT SINK(TR) AVR130/230/330 1
CTB3+8J SCREW 1
HVIL7905CP I.C, REGULATOR 1
IC51 BVIUPD6464A I.C , OSD UPD6464 1
IC51 HVILC74763M I.C , OSD LC74763 1
IC51 HVIUPD6464A IC , OSD UPD6464 1
IC52 HVI74ACT04MTR I.C , HEX 74ACT04 1
JK41 CJJ9N001Z JACK , S-VIDEO (2P/H) 1
JK42 CJJ9N001Z JACK , S-VIDEO (2P/H) 1
JK43 CJJ9S001Z JACK , S-VIDEO (3P/H) 1
JK48 CJJ4N043Z JACK , BOARD 1
JK49 CJJ4N043Z JACK , BOARD 1
JK50 CJJ4S010Z JACK , BOARD 1
JW11 CWEP202110VV WIRE 1
Ref# Component Description 1 Description 2 Qty
IC61 HVINJM2586AMTE1 I.C , VIDEO SW NJM2586 1
Q601 HVTKRC114MT T.R KTC114M 1
R601 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R602 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R603 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R604 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R605 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R606 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R607 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R608 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R609 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1
R610 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R611 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J 1
R612 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1
C610 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1
C611 HCEA1CH101T CAP , ELECT 100UF 16V 1
C612 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1
C613 HCEA1CH101T CAP , ELECT 100UF 16V 1
C620 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1
C621 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1
C622 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1
JK61 CJJ4L009Z JACK 9P (RRR/BBB/GGG) 1
BN61 CWB2B907120EN WIRE ASS'Y 1
Ref# Component Description 1 Description 2 Qty
C124 BCQE2E104KDE CAP , LINE ACROSS 0.1UF 250V KD 1
OL91 KJJ7A025Z OUTLET , EUR(2P) A3-04-D007-2P 1
F901 KBA2D2500TLET FUSE 1
F902 KBA2D2500TLET FUSE 1
BN14 CWB4F232450PU WIRE ASS'Y 1
BN91 CWB4FE53130PU WIRE ASS'Y 1
CN21 KJP02GA89ZM WAFER MOLEX35328-02 1
CN84 KJP05GA19ZM WAFER MOLEX53014-0510 1
VIDEO PCB ASSY
outlet 230V (drawing CUP11747-6)
Component IN/OUT (drawing CUP 11747-2
Harman Consumer Group International HARMAN/KARDON AVR235/230
To Next Page
