Ref# Component Description 1 Description 2 Qty

JK97 CJJ4P041W JACK IN/OUT 1

JK98 CJJ4P042W JACK IN/OUT 1

JW90 CWEE212120VV WIRE ASS'Y 1

JW91 CWE8212180VV WIRE ASS'Y 1

JW99 CWE8202150AA WIRE ASS'Y 1

L501 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L502 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L503 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L504 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L505 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L506 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

L507 CLEY0R5KAK COIL , SPEAKER 0.5UH K 1

Q858 HVT2SA1360O T.R 2SA1360O 1

Q871 HVT2SA1360O T.R 2SA1360O 1

Q872 HVT2SA1360O T.R 2SA1360O 1

Q874 HVT2SA1360O T.R 2SA1360O 1

Q875 HVT2SA1360O T.R 2SA1360O 1

Q876 HVT2SA1360O T.R 2SA1360O 1

Q877 HVT2SA1360O T.R 2SA1360O 1

Q881 HVT2SC3423O T.R 2SC3423O 1

Q882 HVT2SC3423O T.R 2SC3423O 1

Q883 HVT2SC3423O T.R 2SC3423O 1

Q884 HVT2SC3423O T.R 2SC3423O 1

Q885 HVT2SC3423O T.R 2SC3423O 1

Q886 HVT2SC3423O T.R 2SC3423O 1

Q887 HVT2SC3423O T.R 2SC3423O 1

RY94 HSL1A008ZE RELAY SDT-S-112DMR 1

R656 CRF5EKR27HX2K RES , CEMENT 1

R657 CRF5EKR27HX2K RES , CEMENT 1

R658 CRF5EKR27HX2K RES , CEMENT 1

R659 CRF5EKR27HX2K RES , CEMENT 1

R660 CRF5EKR27HX2K RES , CEMENT 1

R810 CRF5EKR27HX2K RES , CEMENT 1

R811 CRF5EKR27HX2K RES , CEMENT 1

R905 CRG1ANJ100H RES , METAL OXIDE FILM 1

R923 CRD25TJ220T RES , CARBON 1

R990 CRG1ANJ100H RES , METAL OXIDE FILM 1

R993 CRG1ANJ100H RES , METAL OXIDE FILM 1

R994 CRG1ANJ100H RES , METAL OXIDE FILM 1

R995 CRG1ANJ100H RES , METAL OXIDE FILM 1

R996 CRG1ANJ100H RES , METAL OXIDE FILM 1

R997 CRG1ANJ100H RES , METAL OXIDE FILM 1

R999 CRG1ANJ100H RES , METAL OXIDE FILM 1

TH91 KRTP42T7D330B THERMAL SENSOR , POSISTOR P42T7D330BW20 1

T902 CLT5J033ZE TRANS , SUB 1

Ref# Component Description 1 Description 2 Qty

COP11769C BIAS T.R PCB ASS'Y 1

C851 HCEA1HH100T CAP , ELECT 10UF 50V 1

C852 HCEA1HH100T CAP , ELECT 10UF 50V 1

C853 HCEA1HH100T CAP , ELECT 10UF 50V 1

C854 HCEA1HH100T CAP , ELECT 10UF 50V 1

C855 HCEA1HH100T CAP , ELECT 10UF 50V 1

C856 HCEA1HH100T CAP , ELECT 10UF 50V 1

C857 HCEA1HH100T CAP , ELECT 10UF 50V 1

R874 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1

R875 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1

R876 CRD20TJ331T RES , CARBON 330 OHM 1/5W J 1

MAIN PCB Assy

BIAS PCB ASSY
