Harman Kardon AVR 2700 Owner's Manual

AVR
System Remote Control Functions
8
S
y
stem Remote Control Functions
Source Selector
Buttons
AVR Power On/Off
Buttons
Audio Effects
Button
Back/Exit
Button
A/B/C/D Buttons
Volume Up/Down
Buttons
Mute Button
Info Button
AVR Button
Zone Selector
Switch
OK Button
Last Channel
Button
Video Modes
Button
IR Transmitter
Device Power
On/Off Buttons
Surround Modes
Button
Number
Buttons
Activity Button
Menu Button
Disc Menu
Button
Sleep Button
Learn Button
(AVR 3700/AVR 370)
Transport Control
Buttons
Channel Up/Down and
Page Buttons
Up/Down/Left/Right
Buttons
Backlight Button
(AVR 3700/AVR 370)

Harman Kardon AVR 2700 Specifications

Audio Section

stereo mode continuous average power	100 watts/ch, 20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms, 6-ohm certified
multichannel power	100 watts/ch, 20Hz – 20kHz, <0.07% THD, two channels driven @ 8 ohms, 6-ohm certified
bandwidth @ 1W (+0dB/–3dB)	10Hz – 130kHz
input sensitivity/impedance (line-in)	200mV/47k ohms
signal-to-noise ratio (IHF-A)	100dB
high instantaneous current capability (HCC)	±35 amps
slew rate	40V/μsec

FM Tuner Section

frequency range	87.5MHz–108.0MHz
usable sensitivity (IHF)	1.3μV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @ 1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	90dB

AM Tuner Section

frequency range	520kHz – 1, 720kHz
signal-to-noise ratio	45dB
usable sensitivity (loop)	500μV
distortion (1kHz)	50%, mod 0.8%
selectivity (±10kHz)	30dB

Video Section

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)

General

power requirement	AC 120V/60Hz
power consumption	120W idle; 1405W maximum
dimensions (W x H x D)	17-5/16" x 6-1/2" x 15" (440mm x 165mm x 382mm)
weight	7.7kg (16.9 lb)
