ENGLISH

AVR

Making Connections,

To control more than one source device through the AVR’s IR Remote Out connector,

connect all sources in “daisy chain” fashion, connecting each device’s IR output to the

next device’s IR input, starting with the AVR.

s If you install a multizone system, connect an IR control device to the Zone 2 IR In

connector for remote-room control of the multizone system, source devices and

volume in the remote zone.

External IR Receiver

Zone 2

Main Room

Zone 2 Speakers

AVR

If a source device is shared with the main listening area, any control commands issued

to that source will also affect the main room.

Connect the Trigger Output

If your system has equipment that can be controlled by a DC trigger signal, connect it to

the AVR’s Trigger Out connector with a mono 1/8-inch (3.5mm) mini-plug interconnect

cable. The AVR will supply a 12V DC (100mA) trigger signal at this connection whenever

it is powered on.

AVR

Device with

Trigger In Connector

Mono 1/8-inch

(3.5mm) Mini-Plug

Interconnect

(not supplied)

Connect to AC Power

Connect the supplied AC power cord to the AVR’s AC Input connector and then to a

working AC power outlet.

AC Power

Outlet

AVR

AC Input

Connector

Power Cord (supplied)
