Harman Kardon AVR 3700 User Manual

AVR
System Remote Control Functions
8
S
y
stem Remote Control Functions
Source Selector
Buttons
AVR Power On/Off
Buttons
Audio Effects
Button
Back/Exit
Button
A/B/C/D Buttons
Volume Up/Down
Buttons
Mute Button
Info Button
AVR Button
Zone Selector
Switch
OK Button
Last Channel
Button
Video Modes
Button
IR Transmitter
Device Power
On/Off Buttons
Surround Modes
Button
Number
Buttons
Activity Button
Menu Button
Disc Menu
Button
Sleep Button
Learn Button
(AVR 3700/AVR 370)
Transport Control
Buttons
Channel Up/Down and
Page Buttons
Up/Down/Left/Right
Buttons
Backlight Button
(AVR 3700/AVR 370)

Harman Kardon AVR 3700 Specifications

Audio Specifications

stereo mode continuous average power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms, 6-ohm certified
multichannel power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, two channels driven @ 8 ohms, 6-ohm certified
input sensitivity/impedance (line-in)	200mV/47k ohms

Video Specifications

television format	NTSC
video frequency response (composite video)	10Hz – 8MHz (–3dB)
input level/impedance	1Vp-p/75 ohms

Power

power requirement	AC 120V/60Hz
power consumption	120W idle; 1, 405W maximum (7 channels driven)
high instantaneous current capability (HCC)	±45 amps

Weight and Dimensions

dimensions (W x H x D)	17-5/16" x 6-1/2" x 15" (440mm x 165mm x 382mm)
weight	17.6 lb (8kg)
