Harman Kardon AVR 3700 User Manual

47
ENGLISH
AVR
Appendix
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR Source
Digital Audio
Connection
Analog Audio
Connection
Video
Connections
Cable TV, satellite TV, HDTV
or other device that delivers
television programs
Cable/SAT HDMI 2 Analog 1 or 2 HDMI 2
DVD Audio/Video, SACD,
Blu-ray Disc, HD-DVD player
Disc HDMI 1 Analog 1 or 2 HDMI 1
Media Server, including
Harman Kardon DMC 1000
Media Server HDMI 4 Analog 1 or 2 HDMI 4
TV TV Optical 1 Analog 1 or 2 None
Video-game console Game HDMI 3 Analog 1 or 2 HDMI 3
Any audio or video device,
e.g., CD player, camcorder,
cassette deck
C (yellow) or D (blue) Coaxial or Optical Analog 1 or 2
Composite Video 1 or 2 (not used
for audio-only devices)
Analog Recorder Any None Analog 1 or 2 Inputs and Rec Out
Composite Video 2 Input and
Monitor Output
iPod or iPhone USB/iPod USB N/A N/A
DVR DVR HDMI 5
Analog 1 or 2
HDMI 5
Table A2 – Source Setting Defaults
Cable/Sat Disc
Media
Server
Radio TV Game AUX
iPod/iPhone
via USB
DVR USB
Surround Modes
(Auto Select)
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Logic 7
Music
Logic 7
Movie
Logic 7
Movie
Logic 7
Movie
Video Input HDMI 2 HDMI 1 HDMI 4 N/A N/A HDMI 3 HDMI Front N/A HDMI 5 N/A
Audio Input HDMI 2 HDMI 1 HDMI 4 N/A
Optical Digital
Audio 1
HDMI 3 HDMI Front N/A HDMI 5 N/A
Resolution to
Display*
480i
(NTSC);
576p (PAL)
480i
(NTSC);
576p (PAL)
480i
(NTSC);
576p (PAL)
480i
(NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
480i
(NTSC);
576p (PAL)
480i (NTSC);
576p (PAL)
N/A
480i (NTSC);
576p (PAL)
480i
(NTSC);
576p (PAL)
Zone 2 Audio — — — Radio — — — — USB
Dolby Volume Medium Low Medium Medium Medium Medium Low Medium Medium Medium
* Video output resolution may vary for HDMI connections. The default HDMI resolution is 1080i for NTSC and PAL.

Harman Kardon AVR 3700 Specifications

Audio Specifications

stereo mode continuous average power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms, 6-ohm certified
multichannel power	125 watts/ch, 20Hz – 20kHz, <0.07% THD, two channels driven @ 8 ohms, 6-ohm certified
input sensitivity/impedance (line-in)	200mV/47k ohms

Video Specifications

television format	NTSC
video frequency response (composite video)	10Hz – 8MHz (–3dB)
input level/impedance	1Vp-p/75 ohms

Power

power requirement	AC 120V/60Hz
power consumption	120W idle; 1, 405W maximum (7 channels driven)
high instantaneous current capability (HCC)	±45 amps

Weight and Dimensions

dimensions (W x H x D)	17-5/16" x 6-1/2" x 15" (440mm x 165mm x 382mm)
weight	17.6 lb (8kg)
