Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
FRONT PCB
R322 1013495091 1 PC RMGCFMIC 680R0 OHM +5% 62MI5W
R323 1013495091 1 PC RMGCFMIC 680R0 OHM +5% 62MI5W
R700 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R701 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R702 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R703 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R704 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R705 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R706 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R707 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R709 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R711 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R713 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R715 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R717 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R718 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R720 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R722 1013465091 1 PC RMGCFMIC 47R0 OHM +5% 62MI5W
R724 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R725 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R726 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R727 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R728 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R729 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R730 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R731 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R732 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R733 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R734 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R735 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R736 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R737 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R738 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R739 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R740 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R741 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R742 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R743 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R744 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R745 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R746 1013478091 1 PC RMGCFMIC 150R0 OHM +5% 62MI5W
R800 1013495091 1 PC RMGCFMIC 680R0 OHM +5% 62MI5W
R801 1013495091 1 PC RMGCFMIC 680R0 OHM +5% 62MI5W
R802 10134810 1 PC RMGCFMIC 180R0 OHM +5% 62MI5W
R803 10134810 1 PC RMGCFMIC 180R0 OHM +5% 62MI5W
RV10 55134900NR 1 PC SWIROT EC16B24204A5 5V 500U0A 10T 3P 0 0
RV30 551799200 1 PC PR-ROT 100K0 OHM NON-LINEAR RK14K12400BR 0 0
RV31 551799200 1 PC PR-ROT 100K0 OHM NON-LINEAR RK14K12400BR 0 0
RV32 551799100 1 PC PR-ROT 100K0 OHM NON-LINEAR RK14K12400BQ 0 0
J400 1032875091 1 PC RMGCFMIC 0 OHM +0% 62MI5W
J401 1032875091 1 PC RMGCFMIC 0 OHM +0% 62MI5W
J402 1032875091 1 PC RMGCFMIC 0 OHM +0% 62MI5W
J404 1032875091 1 PC RMGCFMIC 0 OHM +0% 62MI5W
Miscellaneous
DP10 55142780NR 1 PC DISPLAY HNA-15LL01
FN10 55177570 1 PC AC PUN SHIELD FENCE TONE
L100 5517938016 1 PC LF 4U7H +10% 1.7 OHM 190.0A
L101 5517938016 1 PC LF 4U7H +10% 1.7 OHM 190.0A
L102 5516884016 1 PC LF 47U0H +10% 5.8 OHM 70MI0A
N704 556864000 1 PC WIRECONASY UNIQUE 10P 600MM UL1533 SHIELD 26 1
N706 551757900 1 PC WIRECONASY UNIQUE 4P 100MM UL1007 PVC DISCRETE 26 1
N708 552128100 1 PC WIRECONASY UNIQUE 9P 300MM UL1007 PVC DISCRETE 24
N709 557244600 1 PC WIRECONASY UNIQUE 2P 150MM UL1007 PVC DISCRETE 26 1
N712 556862000 1 PC WIRECONASY DL 2.0MM 10P 450MM UL1533 SHIELD 26 1
NJ80 55171510 1 PC CON PHONO SCKT RCA-313P 3 PINS
