Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
FRONT PCB
NJ81 55113960 1 PC CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J
P705 55090030 1 PC CONN 2.0MM 4 MA R NAT LW2003P04 0 0
P710 55230490 1 PC CONN 1.25MM 31 FE R BK 00-6216-031-120-808 0 0
P711 55124740 1 PC CONN 1.25MM 15 FE R BK 00-8370-157-000-800 2794 A6
Y100 55126140NR 1 PC CRESONATOR 10M0 HZ 25.0 OHM 0F
S200 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S201 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S202 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S203 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S204 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S205 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S206 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S207 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S208 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S209 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S211 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S212 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S213 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S214 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S215 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S216 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S217 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S218 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S219 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
S220 55145270KX 1 PC SWITACT VERTICAL TACTILE F/B 50MI0A 12.0V 500MI0OHM 1T 1P
3 CHANNEL AMP
Capacitors
C109 552327300 1 PC CE 120U0F +20% 100.0V 85C
C110 552327300 1 PC CE 120U0F +20% 100.0V 85C
C111 552327300 1 PC CE 120U0F +20% 100.0V 85C
C112 552327300 1 PC CE 120U0F +20% 100.0V 85C
C209 552327300 1 PC CE 120U0F +20% 100.0V 85C
C210 552327300 1 PC CE 120U0F +20% 100.0V 85C
C211 552327300 1 PC CE 120U0F +20% 100.0V 85C
C212 552327300 1 PC CE 120U0F +20% 100.0V 85C
C309 552327300 1 PC CE 120U0F +20% 100.0V 85C
C310 552327300 1 PC CE 120U0F +20% 100.0V 85C
C311 552327300 1 PC CE 120U0F +20% 100.0V 85C
C312 552327300 1 PC CE 120U0F +20% 100.0V 85C
C101 1012100039 1 PC CE 10U0F +20% 16.0V 85C
C102 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C103 4043358071 1 PC CC 680P0F +10% -10% 50.0V Y5P
C104 5524629039 1 PC CE 100U0F +20% 25.0V 85C
C105 3093607071 1 PC CC 12P0F +5% -5% 50.0V NP0
C106 7042837071 1 PC CC 220P0F +10% -10% 50.0V Y5P
C107 2041669070 1 PC CPM 100N0F +20% 250.0V
C108 2041669070 1 PC CPM 100N0F +20% 250.0V
C113 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C114 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C115 1307794071 1 PC CPF 10N0F +10% 100.0V
C116 1307794071 1 PC CPF 10N0F +10% 100.0V
C117 5517940071 1 PC CPM 68N0F +5% 63.0V
C118 2025267030 1 PC CE 470U0F +20% 10.0V 85C
C161 1036482071 1 PC CPF 47N0F +10% 100.0V
C162 1307201071 1 PC CPF 4N7F +10% 100.0V
C164 1307201071 1 PC CPF 4N7F +10% 100.0V
C201 1012100039 1 PC CE 10U0F +20% 16.0V 85C
C202 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C203 4043358071 1 PC CC 680P0F +10% -10% 50.0V Y5P
C204 5524629039 1 PC CE 100U0F +20% 25.0V 85C
C205 3093607071 1 PC CC 12P0F +5% -5% 50.0V NP0
C206 7042837071 1 PC CC 220P0F +10% -10% 50.0V Y5P
C207 2041669070 1 PC CPM 100N0F +20% 250.0V
C208 2041669070 1 PC CPM 100N0F +20% 250.0V
C213 2026901030 1 PC CE 47U0F +20% 50.0V 85C
34
AVR7200 harman/kardon
