Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
3 CHANNEL AMP
C214 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C215 1307794071 1 PC CPF 10N0F +10% 100.0V
C216 1307794071 1 PC CPF 10N0F +10% 100.0V
C217 5517940071 1 PC CPM 68N0F +5% 63.0V
C218 2025267030 1 PC CE 470U0F +20% 10.0V 85C
C261 1036482071 1 PC CPF 47N0F +10% 100.0V
C262 1307201071 1 PC CPF 4N7F +10% 100.0V
C264 1307201071 1 PC CPF 4N7F +10% 100.0V
C301 1012100039 1 PC CE 10U0F +20% 16.0V 85C
C302 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C303 4043358071 1 PC CC 680P0F +10% -10% 50.0V Y5P
C304 5524629039 1 PC CE 100U0F +20% 25.0V 85C
C305 3093607071 1 PC CC 12P0F +5% -5% 50.0V NP0
C306 7042837071 1 PC CC 220P0F +10% -10% 50.0V Y5P
C307 2041669070 1 PC CPM 100N0F +20% 250.0V
C308 2041669070 1 PC CPM 100N0F +20% 250.0V
C313 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C314 2026901030 1 PC CE 47U0F +20% 50.0V 85C
C315 1307794071 1 PC CPF 10N0F +10% 100.0V
C316 1307794071 1 PC CPF 10N0F +10% 100.0V
C317 5517940071 1 PC CPM 68N0F +5% 63.0V
C318 2025267030 1 PC CE 470U0F +20% 10.0V 85C
C361 1036482071 1 PC CPF 47N0F +10% 100.0V
C362 1307201071 1 PC CPF 4N7F +10% 100.0V
C364 1307201071 1 PC CPF 4N7F +10% 100.0V
C901 2025267030 1 PC CE 470U0F +20% 10.0V 85C
C902 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C903 2041669070 1 PC CPM 100N0F +20% 250.0V
C904 2041669070 1 PC CPM 100N0F +20% 250.0V
C917 2026898030 1 PC CE 22U0F +20% 50.0V 85C
C918 2025267030 1 PC CE 470U0F +20% 10.0V 85C
Semiconductors
D107 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D207 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D307 20525530NR 1 PC D-SR 1N4003 200.0V 1A
Q108 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q109 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q110 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q111 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q112 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q114 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q115 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q116 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q117 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q118 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q119 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q120 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q121 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q208 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q209 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q210 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q211 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q212 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q214 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q215 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q216 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q217 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q218 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q219 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q220 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q221 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q308 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q309 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q310 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q311 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
35
AVR7200 harman/kardon
