Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
3 CHANNEL AMP
Q312 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q314 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q315 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q316 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q317 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q318 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q319 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q320 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q321 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q101 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q102 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q103 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q104 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q105 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q106 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q107 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q122 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q123 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q201 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q202 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q203 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q204 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q205 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q206 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q207 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q222 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q223 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q301 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q302 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q303 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q304 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q305 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q306 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q307 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q322 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q323 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q901 5513326056 1 PC TR-SLPLF KTA1024 Y P 50MI0A -150V
Q902 5513321056 1 PC TR-SLPLF DTC114YSA N 100MI0A
Q925 2050821056 1 PC TR-SLPLF KTA1266 Y P 150MI0A
Q926 5513325056 1 PC TR-SLPLF 2SC1740S R N 150MI0A 50V
Q927 5513325056 1 PC TR-SLPLF 2SC1740S R N 150MI0A 50V
Q928 5513325056 1 PC TR-SLPLF 2SC1740S R N 150MI0A 50V
D101 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D102 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D103 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D104 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D105 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D108 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D201 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D202 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D203 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D204 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D205 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D208 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D301 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D302 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D303 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D304 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D305 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D308 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D901 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D902 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D907 20526960 1 PC D-ZENER 1N5231B 5.1V 500MI0W
D908 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D909 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D910 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
