Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
3 CHANNEL AMP
Resistors
R130 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R131 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R138 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R139 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R161 1502271016 1 PC RMOF 10R0 OHM +5% 2.0W
R171 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R172 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R230 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R231 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R238 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R239 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R261 1502271016 1 PC RMOF 10R0 OHM +5% 2.0W
R271 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R272 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R330 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R331 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R338 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R339 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R361 1502271016 1 PC RMOF 10R0 OHM +5% 2.0W
R371 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R372 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R101 1105964016 1 PC RCF 1K0 OHM +5% 250MI0W
R102 5523153016 1 PC RMF 33K0 OHM +1% 125MI0W +100PPM/'C
R103 4043563016 1 PC RCF 1K5 OHM +5% 250MI0W
R104 4043563016 1 PC RCF 1K5 OHM +5% 250MI0W
R105 5088297016 1 PC RCF 470R0 OHM +5% 250MI0W
R106 5088295016 1 PC RCF 100R0 OHM +5% 250MI0W
R107 5088295016 1 PC RCF 100R0 OHM +5% 250MI0W
R108 5088295016 1 PC RCF 100R0 OHM +5% 250MI0W
R109 2046945016 1 PC RCF 220R0 OHM +5% 250MI0W
R110 5523280016 1 PC RMF 82R0 OHM +5% 500MI0W
R111 5523153016 1 PC RMF 33K0 OHM +1% 125MI0W +100PPM/'C
R112 1106089016 1 PC RMF 2K43 OHM +1% 250MI0W
R113 1501565016 1 PC RMF 2K67 OHM +1% 250MI0W
R114 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R115 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R116 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R117 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R118 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R119 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R120 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R121 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R122 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R123 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R124 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R125 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R126 2046946016 1 PC RCF 2K2 OHM +5% 250MI0W
R129 8043698016 1 PC RCF 620R0 OHM +5% 250MI0W
R132 5523277016 1 PC RMF 2R2 OHM +5% 500MI0W
R133 5523277016 1 PC RMF 2R2 OHM +5% 500MI0W
R134 5523278016 1 PC RMF 100R0 OHM +5% 500MI0W
R135 5523278016 1 PC RMF 100R0 OHM +5% 500MI0W
R136 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R137 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R140 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R141 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R142 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R143 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R144 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R145 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R146 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R147 2046949016 1 PC RCF 6K8 OHM +5% 250MI0W
R148 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R149 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R150 3093949016 1 PC RCF 33K0 OHM +5% 250MI0W
37
AVR7200 harman/kardon
