Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
4 CHANNEL AMP
Q501 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q502 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q503 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q504 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q505 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q506 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q507 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q522 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q523 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q601 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q602 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q603 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q604 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q605 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q606 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q607 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q622 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q623 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q701 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q702 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q703 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q704 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q705 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q706 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q707 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q722 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q723 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q801 5513326056 1 PC TR-SLPLF KTA1024 Y P 50MI0A -150V
Q802 5513321056 1 PC TR-SLPLF DTC114YSA N 100MI0A
D401 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D402 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D403 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D404 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D405 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D408 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D501 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D502 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D503 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D504 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D505 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D508 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D601 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D602 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D603 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D604 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D605 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D608 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D701 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D702 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D703 5523140016 1 PC D-SLP 1SS244 220.0V 200MI0A
D704 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D705 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D708 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D801 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D802 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
Resistors
R430 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R431 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R438 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R439 55232750NR 1 PC RMF 2R2 OHM +5% 1.0W
R461 1502271016 1 PC RMOF 10R0 OHM +5% 2.0W
R471 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R472 55307540NR 1 PC RW 270MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R530 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
R531 55232760NR 1 PC RMF 56R0 OHM +5% 1.0W
43
AVR7200 harman/kardon
