Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
4 CHANNEL AMP
R735 5523278016 1 PC RMF 100R0 OHM +5% 500MI0W
R736 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R737 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R740 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R741 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R742 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R743 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R744 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R745 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R746 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R747 2046949016 1 PC RCF 6K8 OHM +5% 250MI0W
R748 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R749 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R750 3093949016 1 PC RCF 33K0 OHM +5% 250MI0W
R755 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
R756 2046946016 1 PC RCF 2K2 OHM +5% 250MI0W
R757 1105958016 1 PC RCF 56R0 OHM +5% 250MI0W
R770 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
R801 6044154016 1 PC RCF 180R0 OHM +5% 250MI0W
R802 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
Miscellaneous
B401 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B402 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B403 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B404 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B501 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B502 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B503 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B504 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B601 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B602 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B603 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B604 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B701 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B702 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B703 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B704 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
G401 55135980NR 1 PC TERMLUG GND
G501 55135980NR 1 PC TERMLUG GND
G601 55135980NR 1 PC TERMLUG GND
G701 55135980NR 1 PC TERMLUG GND
G802 55135980NR 1 PC TERMLUG GND
G803 55135980NR 1 PC TERMLUG GND
L401 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
L501 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
L601 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
L701 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
N401 557207200 1 PC WIRECONASY UNIQUE 6 260MM UL1007 RIBBON 24 1
N403 556868500 1 PC WIRECONASY UNIQUE 2P 380MM UL1007 RIBBON 18 1
N501 556868100 1 PC WIRECONASY UNIQUE 5P 150MM UL1007 RIBBON 24 1
N503 556868800 1 PC WIRECONASY UNIQUE 2P 300MM UL1007 PVC DISCRETE 18 12
N601 556868900 1 PC WIRECONASY UNIQUE 4P 180MM UL2547 24 12
N603 556869000 1 PC WIRECONASY UNIQUE 2P 240MM UL1007 PVC DISCRETE 18 12
N701 556869100 1 PC WIRECONASY UNIQUE 3P 250MM UL2547 24 12
N703 556869200 1 PC WIRECONASY UNIQUE 2P 120MM UL1007 PVC DISCRETE 18 12
N801 556869300 1 PC WIRECONASY UNIQUE 2P 170MM UL1007 PVC DISCRETE 18 12
N802 556869400 1 PC WIRECONASY UNIQUE 2P 200MM UL1007 PVC DISCRETE 18 12
N803 556867700 1 PC WIRECONASY UNIQUE 4P 180MM UL1007 PVC DISCRETE 16 1
N805 556867200 1 PC WIRECONASY UNIQUE 2P 220MM UL1007 PVC DISCRETE 16 1
N905 555873900 1 PC POS 100R0 OHM 16.0V
NJ41 55637150NR 1 PC CONN-SPE SPEAKER TER'BOARD(2P) RD/BK D/N B30290111N
NJ51 55637160NR 1 PC CONN-SPE SPEAKER TER'BOARD(2P) GY/BK D/N B30290115N
47
AVR7200 harman/kardon
