Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
4 CHANNEL AMP
NJ61 55637210NR 1 PC CONN-SPE SPEAKER TER'BOARD(4P) GN/BK/TAN/BK B30490163N
P401 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P402 55146570 1 PC CONN 2.5MM 3 MA ST NAT 0 0
P406 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P416 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P417 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P418 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P419 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P501 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P506 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P601 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P606 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P701 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P706 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P802 55169140 1 PC CON 3.96MM PITCH MOREX 35313-0210
P905 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
SK41 55568280 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
SK51 55568280 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
SK61 55568280 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
SK71 55568280 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
W401 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
W402 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
W403 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
W404 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
W405 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
W406 556870600 1 PC WIRESSTRINS 4.0 CU WIRE 70MM BK 80C Y
DSP PC
B
Capacitors
C103 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C107 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C108 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C109 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C146 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C147 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C148 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C149 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C194 2034206039 1 PC CE 47U0F +20% 16.0V 85C
C231 20269180AM 1 PC CE 1MI0F +20% 6.3V 85C
C239 20269180AM 1 PC CE 1MI0F +20% 6.3V 85C
C240 20269180AM 1 PC CE 1MI0F +20% 6.3V 85C
C999 2050657091 1 PC CCCFMIC 47P0F +5% -5% 50.0V NP0
C117 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C199 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C232 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C286 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C288 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C289 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C290 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C291 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C292 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C293 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C294 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C295 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C296 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C297 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C298 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C299 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C300 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C301 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C302 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C303 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
C304 2028804091 1 PC CCCFMIC 100N0F +80% -20% 16.0V Y5V
48
AVR7200 harman/kardon

Harman Kardon AVR 7200 Specifications

General

Brand	Harman Kardon
Model	AVR 7200
Category	Receiver
Language	English
