Coaxial Digital Audio Inputs: Connect the coax
digital audio output from a DVD player, HDTV receiver,
the S/P-DIF output of a compatible computer
sound card
playing MP3 files or streams,LD player
or CD player to
these jacks.The signal may be a Dolby Digital signal,
DTS signal or a standard PCM digital source.Do not
connect the RF digital output of an LD player to
these jacks.
Video 1 Inputs: Connect the analog audio and
composite or S-Video PLAY/OUT jacks of a VCR or
other video source to these jacks.
8-Channel Direct Inputs: These jacks are used
for connection to source devices such as DVD-Audio
or SACD players with discrete analog outputs.Depending
on the source device in use,all eight jacks may be
used, though in many cases only connections to the
front left/right, center, surround left/right and LFE (sub-
woofer input) jacks will be used for standard 5.1 audio
signals.
RS-232 Port:This jack is used to enable the
AVR 7200 to be controlled by an external computer
or programmable remote system that uses RS-232
commands.Due to the complexity of RS-232 con-
nections,we recommend that they be made only by
a trained and qualified custom installer. See page 36
for more information on the RS-232 control port.
35
34
33
32
REAR-PANEL CONNECTIONS
10 REAR-PANEL CONNECTIONS
AVR 7200 OM 1/27/03 4:46 PM Page 10
