CXP82532/82540
Provides voltage for FDP when on-chip resistor is selected under mask
option.
Connection for system clock oscillation crystal. When using an external
clock, input normal signal to EXTAL and reverse phase signal to the
XTAL pin.
System reset, active "L". The RST pin is an input/output pin which
outputs a "L" level from the on-chip power-on reset circuit when the
power is turned on. (Mask option)
NC pin is always connected to VDD.
Positive power supply pin.
GND
Symbol I/O Description
V
FDP
EXTAL
XTAL
RST
NC
VDD
VSS
Input
Output
I/O
