Harman Kardon AVR325 - Page 79

Ref.
Designator
Qty Description
FRONT PCB
IC12
20718660MT 1
PC
IC-LOGIC BU4094BF SHIFT REGISTER CMO
S
IC13
20718660MT 1
PC
IC-LOGIC BU4094BF SHIFT REGISTER CMO
S
IC14
20718660MT 1
PC
IC-LOGIC BU4094BF SHIFT REGISTER CMO
S
IC15
55087180MT 1
PC
IC-LOGIC BU4051BCF MULTIPLEXER HC
T
IC16
55179630NR 1
PC
PHOTCOUP PC-17T1 PHOTOCOUPLER DIP
4
IC30
55142240MU 1
PC
IC-OPERAMP NJM2068DD DUAL O
P
Q100
5514267056 1
PC
TR-SLPLF MPSA06 N 500MI0
A
Q106
5513321056 1
PC
TR-SLPLF DTC114YSA N 100MI0
A
Q107
5513321056 1
PC
TR-SLPLF DTC114YSA N 100MI0
A
Q108
5513321056 1
PC
TR-SLPLF DTC114YSA N 100MI0
A
Q109
5513321056 1
PC
TR-SLPLF DTC114YSA N 100MI0
A
Q110
5513321056 1
PC
TR-SLPLF DTC114YSA N 100MI0
A
Q111
5513318092 1
PC
TR-SSD DTC114YKA N 10K0 OHM 47K0 OH
M
Q112
5513318092 1
PC
TR-SSD DTC114YKA N 10K0 OHM 47K0 OH
M
Q114
5513318092 1
PC
TR-SSD DTC114YKA N 10K0 OHM 47K0 OH
M
Q115
5513318092 1
PC
TR-SSD DTC114YKA N 10K0 OHM 47K0 OH
M
Q116
5517922056 1
PC
TR-SLPSWA KRA107M P
Q700
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q701
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q702
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q703
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q704
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q705
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q706
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q707
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q708
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q709
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q710
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q711
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q712
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q713
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q714
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q715
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q716
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q717
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q718
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q719
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q720
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q721
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Q722
5513333092 1
PC
TR-SSD DTC114TKA N 10K0 OH
M
Resistor
s
R100
1013529091 1
PC
RMGCFMIC 68K0 OHM +5% 62MI5W
R101
1013529091 1
PC
RMGCFMIC 68K0 OHM +5% 62MI5W
R102
1013594091 1
PC
RMGCFMIC 4K7 OHM +5% 62MI5W
R103
1013441091 1
PC
RMGCFMIC 10R0 OHM +5% 62MI5W
R104
1013522091 1
PC
RMGCFMIC 47K0 OHM +5% 62MI5W
R105
1013534091 1
PC
RMGCFMIC 100K0 OHM +5% 62MI5W
R106
1013600091 1
PC
RMGCFMIC 8K2 OHM +5% 62MI5W
R108
1013501091 1
PC
RMGCFMIC 10K0 OHM +5% 62MI5W
R119
1013501091 1
PC
RMGCFMIC 10K0 OHM +5% 62MI5W
R120
1013501091 1
PC
RMGCFMIC 10K0 OHM +5% 62MI5W
R121
1013501091 1
PC
RMGCFMIC 10K0 OHM +5% 62MI5W
R122
1013501091 1
PC
RMGCFMIC 10K0 OHM +5% 62MI5W
R123
1013594091 1
PC
RMGCFMIC 4K7 OHM +5% 62MI5W
R124
1013594091 1
PC
RMGCFMIC 4K7 OHM +5% 62MI5W
