Harman PF100 User Manual

8
3-90-08101R23_06/13
Assembly
Firebrick installation-required
The rebrick is shipped in theash pan.It will needto be
placed on the brick shelf as shown in Fig. 15. It can be
installedwitheitherfacetothere.Holdthebricklongways
andslideitdownintotheslotontheshelf.Thereisastop
attherearoftheshelftostoptherearwardtravel.Thebrick
justsitsontheshelfintheuprightposition.
Bafe installation
Theupperheatexchangerbafecomesshippedalongside
theashpan.Removetheashpanandthebafe.Thisupper
bafeneedstobeinstalledbeforeoperatingthefurnace.
Thebafehasalong45degreebendonthebottomofthe
reboxside.SeeFig.17.
Ontheoppositesidetherearefourhooksthatwillsupport
thebafe.Onthefrontandrearofthereboxwallsthereare
slotsthatthesehookstinto.SeeFig.16
Slidetheupperbafedowntomeettheslots,whileyouhold
thebafeagainst theheatexchanger.Youwill noticethat
theupperbafewillholdthelowerbafeplateintoposition.
SeeFig.17.
Notehowtheupperandlowerbafesareheldinto
positionbecausetheywillneedtoberemovedduringheat
exchangercleaning.
Firebrick
Fig. 15
Fig. 16
Bafesupportbracket
Fig. 17
Upper heat
exchanger bafe
45
o
bend
