Pinnacle Stair Lift
Safety Features
• There are sensitive edges on the top and bottom of the carriage, and the front, back and underside of the
footrest. If any of these edges touches an obstruction the lift will halt immediately and the armrest LED
indicator light will turn orange. The lift may only be driven away from the obstruction.
• An interlock on the swivel seat prevents the lift from being operated unless the seat is in its normal, locked
position. The remote controls are disabled for a 15 second period after the armrest control is used.
Stair Lift Features
Up/Down Control
Seat Swivel Level
Chassis Safety
Footrest Safety
Bottom Safety
Rack
Rail
Seatbelt
Armrest
Key Lock
Top Safety
LED Indicator
On/O Switch
Manual Hand Crank
Remote Control
Optional Signature Seat and Folding Rail Shown
