Pinnacle Stair Lift
Owner Information & Troubleshooting
Owner Information
Thank you for purchasing an SL 6001Pinnacle™ Stair Lift
from Harmar. This is the most trouble-free stair lift on
the market today. It is our hope this lift will provide the
independence you want in your day-to-day life.
Date purchase_____________________________
Lift serial number__________________________
If warranty work or service is needed, your dealer will
need the data above to receive factory information or
order parts for this lift.
Troubleshooting
• If your lift does not operate, diagnose the
problem by observing the LED indicator light on
the armrest and listening to the beeps emitted:
• A green light indicates the lift is in operating
mode and may be moved in either direction.
• An amber light indicates the lift is touching an
obstruction and may be operated only in the
direction away from the obstruction.
• A ashing amber light, accompanied by an
intermittent beep for 30 seconds indicates the
lift has been stopped o the charge station. This
repeats every 5 minutes until the lift is returned
to the charge station. It is recommended that
the lift be immediately moved to a charge
station (located at either end of the rail).
• A red light indicates a problem that may
require a service call. If the light remains red
after attempting to reset the lift by turning
it “OFF” and then “ON” again, please contact
your local dealer or Harmar and describe the
problem. A local technician will need to be
contacted to repair the problem if it cannot be
repaired over the phone
.
Minor faults
Single long beep (will reset once fault is cleared)
• Seat swiveled out of position
• Edge safety detected
• Under foot rest
• Current overload condition
• A Low battery voltage condition
Pulsing Beep
Lift stopped o of charge strip. Will sound after 30
second for 30 seconds. It will repeat ever 10 minutes
until lift is operated or returned to charge strips.
Major Tones
Tones Beeps
Runaway ....................................................................... 1
No Power ........................................................................2
Conicting Switches Footrest UP & Footrest DOWN ...............................3
Conicting Switches Obstruction UP & Obstruction Down .........................4
Conicting Switches Footrest DOWN & Obstruction UP ...........................5
Conicting Switches Footrest UP & Obstruction DOWN ...........................6
Conicting Switches STOP UP & STOP DOWN switches both Detected .............7
Conicting Switches STOP UP & STOP DOWN switches both not Detected .........8
