D-G 16 S2 - 18.04.13 / Vers.: 1
11
3. Remove filter bag with mesh basket (48).
Danger
Switch off unit at main switch (12)! Pull out mains supply plug!
4. Unscrew 4x hexagonal socket screws (60) and remove cover (66).
5. Unscrew 2x knurled screws (43) in filter chamber (51) and remove the strip (17) upwards.
6. Remove super-fine filter (7) upwards.
Caution
There should be no dust lying on the sealing surfaces (49) or in the suction chamber (47), as
dust could possibly damage the extraction motor (46). The filter chamber (51), suction chamber
(47) and sealing surfaces (49) should be suction cleaned.
7. Insert cleaned or new super-fine filter (7).
8. Insert strip (17) from above.
9. Tighten the 2x knurled screws (43) firmly and evenly again.
10. Replace cover (66) and tighten with 4x hexagonal socket screws (60).
11. Shove in the mesh basket (48) together with the inserted filter bag (14) and press the plastic
connection (41) onto the connecting piece (40) with both hands.
12. Inspect filter installation. (See section “3.3”).
4.3 Cleaning the shove-in sieve (embedded material residue)
(see diag. 1 & 2 page 4 & 5)
1. Unscrew knurled nuts for shove-in sieve (10).
2. Pull out shove-in sieve (8) and clean.
3. Firmly tighten the knurled nuts manually after inserting the shove-in sieve.
4.4 Draining of the abrasive
(see diag. 1 page 4)
1. Position unit with sand drainage outlet on table edge.
2. Drain blasting agent by removing plastic sand outlet cover (13).
Note On this occasion, the shove-in sieve (8) should also be removed and cleaned.
(See section “4.3”)
